High Quality Z3050X16/1 Vertical Radial Drilling Machine Price

US$11,000.00
1-9 Sets
US$10,000.00
10+ Sets

Basic Info.

Model NO.
Z3050x16/1
Structure
Radial Drilling Machine
Layout
Vertical
Controlling Mode
Artificial
Number of Shaft
3
Hole Diameter
50-100mm
Automatic Grade
Semiautomatic
Precision
Precision
Certification
GS, CE, RoHS, ISO 9001
Condition
New
Name
Radial Arm Drilling Machine
Max. Drilling Diameter
50mm
Diameter of Column
350mm
Taper of Spindle
Mt5
Spindle Travel
315mm
Spindle Speeds Range
25-2000rpm
Radial Arm Rotation Angle
360 Degree
Spindle Motor Power
4kw
Dimension of Worktable Surface
630X500X500mm
Key Word
Radial Drilling Machine
Function
Drilling Hole for Metal
Delivery Time
40 Days
Distance Spindle Axis to Column Generati
1600mm
Clamping
Hydraulic Clamping
Voltage
OEM
Transport Package
Wooden Case
Specification
50mm diameter
Trademark
BETA
Origin
Shandong, China
Production Capacity
100 Sets Per Month

Packaging & Delivery

Package Size
260.00cm * 112.00cm * 260.00cm
Package Gross Weight
3650.000kg

Product Description


High Quality Z3050x16/1 Vertical Radial Drilling Machine Price
Model Unit Z3050x16/1
Max. Drilling capacity mm 50
Distance spindle axis to column generating line mm 350-1600
Diameter of column mm 350
Taper of spindle MT5
Spindle travel mm 315
Spindle speeds range r/min 25-2000
Spindle speeds series step 16
Spindle feeds range mm/r 0.04-3.2
Spindle feeds step step 16
Max. spindle nose to base mm 320-1220
Dimension of worktable surface mm 630x500x500
Dimension of base mm 2400x1000x200
Overal size mm 2500x1060x2650
Spindle motor power W 4
G.W/N.W kg 3400/3650
Packing dimension mm 2600x1120x2600

Features:
1. The radial drilling machine construction designed elaborately, with pefect appearance and convenient maintenance.
2. The headstock radial arm and column are clamped by manual clamping mechanisms.
3. All controls centrealized on the headstock easy operation and change. Clamping for assemblies and speed change of spindle achieved by hydraulic power.
4. Main parts are made by machine center which import from KIA with high precision and efficiency, ensuring reliability and high quality.
5. Integrating technology for casting parts is excellent, adopting casting equipment, ensuring high quality of materia for basic parts.
6. Spindle parts are made by special high quality steel heat treatment to be made by first class equipments, ensuring high strength and durability.
7. Main gears are machined by gear grinding, ensuring high precision and low noise.
Standard accessories:
Box shape worktable, Taper sleeve, Tool releasing wrench, Drift, Eyelet bolts
Radial drilling machine is a type of drilling machine where the radial arm can rotate and lift around the column, and the spindle box usually moves horizontally on the rocker arm. When machining holes on a vertical drilling machine, the alignment between the tool and the workpiece is achieved through the movement of the workpiece, which is obviously very inconvenient for some large and heavy workpieces; The radial drilling machine can be aligned by moving the position of the tool shaft, which brings great convenience to machining holes on large and heavy workpieces in single and small batch production.
It can also be called a radial drill. It is a hole processing equipment that can be used for various forms of processing, such as drilling, expanding, reaming, tapping, and scraping the end face. According to the clamping structure of machine tools, radial drills can be divided into hydraulic radial drilling machines and mechanical radial drilling machines. Among various types of drilling machines, radial drilling machines are easy to operate, flexible, and have a wide range of applications. They are typical and particularly suitable for single piece or batch production of holes with large porous parts. They are common machine tools in general mechanical processing workshops.
