Basic Info.
Horizontal Resolution
480tvl
Certification
CE, FCC, RoHS
Feature
Waterproof / Weatherproof, Mini Size
Remote Control
Without Remote Control
Storage Capacity
up to 128g
Night Version
High Quality
Pre Recording
60 Seconds(up to Resolution and Video Quality)
Battery Capacity
Built-in 4200mAh
Charge Time
Approximate 4 Hours
System Languages
Multiple
Production Capacity
10000/Month
Product Description
Product Description
Chipset | Ambarella H22 |
Size | 81.5*56.9*30.8mm |
Weight | 146g±5g |
Sensor | 4M CMOS |
Pre-recording | 60 seconds(up to resolution and video quality) |
Video resolution | 2688 ×1512 30P 2560×1440 30P 2304×1296 30P 1920×1080 30P 1280×720 30P 864×480 30P |
Video split time | 3Min/5Min/15Min/30Min/45Min |
Video format | MP4 H.264 &H.265 |
Photo size | 5M/20M/25M/30M/40M |
Snap Shot | Take pictures during recording or in stand-by |
Angle | 140° |
Battery capacity | Built-in 4200mah |
Battery life(gps/ir/lcd off, normal temp, H.264) | 17hrs @868*480 30P 16 hrs @1280*720P 30P 15 hrs @1920*1080 30P 13 hrs@2305*1296 30P 12.5hrs @2560*1440 30P 12hrs @2688*1512 30P |
Charge time | Approximate 4.5 hours |
Take picture while video recording | Yes |
digital zoom | Up to 32X |
Wi-Fi | / |
GPS | Yes |
4G | / |
EIS (Electric Image Stabilization) | / |
G-Sensor | / |
Motion detection | Yes |
AES 256 encryption | Neutra fw dont have, but can accept customization |
Infrared night vision | High quality night vision |
Storage (Memory) | Brand MicroSD Class10 16G/32G/64G/128GB (Standard 32GB) |
TFT screen | 2 inches IPS screen |
Waterproof | IP66~IP68 |
White light | Yes |
Pre - recording | OFF/ON |
Loop-recording | OFF/ON |
Sound volume | 0~12 |
Time zone | -12~12 |
Password protecting | Yes |
Watermark | User ID, Time and date Stamp,GPS coordinates embedded into Video. |
Mulit languages | Portuguese,English,Russian, Japanses, Polish, French, Spanish etc |
Storage temperature | -20ºC~60ºC |
Store humidity | 15%~90% |
Working temperature | -20ºC~60ºC |
Working humidity | 15%~90% |
Support External cam or not | Yes |
USB port type | Type c USB |
Standard Accessories | USB cable, Rotatable Crocodile Clip, Wall Charger, Charging Dock, Rotatable Epaulette Clip,User Manual |
Body Worn Camera Function Show
GPS module
Motion Detection
High quality night vision
Waterproof
IP66 ~ IP68 ( can be customized) A LED camera with IP66 waterproof level is able to withstand water with high-pressure during the test as well as in real life conditions. You can install and leave such an appliance in areas with heavy rains or powerful water jets without worrying about possible damages since you're assured that no harmful quantities of water will be able to penetrate it.
140° Wide Angle Lens
Loop recording
Company Profile
Shenzhen Eeyelog Technology Co., Ltd., established in May 2012, is a professional hightech enterprise with rich experience in R&D, production and sales of imaging&security products, such as body worn cameras, docking stations, dash cameras, etc. With a professional team of around 100 staff, 1000m² modern production workshop, high&low temperature test chamber, professional SMT line, lens focusing and mold injection workshop, Eeyelog's annual revenue is over 12 Million US dollars. Our products are widely used in the domestic public security/urban management/railway system market, and also sold to Asia, Europe, North America, Latin America, Australia etc. Technology innovation is the basic concept of Eeyelog's R&D team. Rich technical experience and sharp market observation make Eeyelog one of the leading pioneers in the imaging&security industry. In addition, the reliable product quality and prompt after-sale service provide a strong guarantee for Eeyelog's sustainable development. In the future, by continuous product researching, technology innovation, better services and further cooperation with universities and professional institutions, Eeyelog will create better quality products and contribute our best efforts to the development of human civilization.
FAQ
Q:Are we factory?
A:Yes. We are in Shenzhen, with 1000 square meters factory area.
Q:What are our featured products?
A:Dash Camera and Body Camera.
Q:What chipset supplier do we cooperate with?
A:Ambarella.
Q:Do we have certificate?
A:Yes. We have CE, RoHS, FCC, E-mark, etc.
Q:Do we supply OEM and ODM service?
A:Yes. Cutomized products and packing are available.
ODM project is welcome.
Q:What is our main market?
A:Our products mainly sell to Europea and America, such as Russia,USA, etc.
Q:Do we have warranty?
A:Yes. 12 months for Dash Camera and Body Camera.
Q:Do we supply samples?
A:Yes. Samples and trial order are available.
>>
