| Rated Current | IEC 62196-2/Type 2 (16A/32A) |
| Rated Current Phase | 3 Phase |
| Operate Voltage | AC 380V ± 10 % |
| Mechanical life | No-load plug in /out >20000 times |
| Insulation Resistance | >1000M Ω (DC500V) |
| Terminal Temperature Rise | <50K |
| Withstand Voltage | 2000V |
| Contact Impedance | 0.5m Ω Max |
| UV Resistant | Yes |
| Coupled Insertion Force | 45N<100n |
| Working Temperature | -30ºC~+50ºC |
| Plug Material | PC+nylon alloy,flame retardant grade UL94 V-O |
| Terminal | Copper alloy, silver plating |
| Sealing Gasket | Rubber or silicon rubber |
| Impact of External Force | Ability to withstand 1M height drop and the rolling of a 2T-vehicle |
| Customization | Wire length, wire diameter, color, laser-printed logo, etc |
