Innovative Hzs180d Skip Loading Ready Cement Mixing Plant

Product Description

Designed for minimum space requirement and large quantities of concrete production performance, durable container modules enable economical transportation,minimum time and operations of erection and disassembling,robust structure reduces the requirement of foundation,leading to economical plant relocations,plant fully enclosed and protected from harsh environment,also low noise and dust emission.

Item		Unit	HZS180D
Nominal output/h		m³/h	180
Mixer charging		m³	3
Batching machine			PLD4800QD-IV
Aggregate storage bins charging		m³	20
Aggregate storage bins qty		pc	4
Aggregate weighing capacity		kg	4*3000
Cement weighing capacity		kg	1600
Fly-ash weighing capacity		kg	600
Water weighing capacity		kg	800
Additive weighing capacity		kg	80
Mixer power		kw	2*55
Belt conveyor power		kw	45
Total power		kw	190
Mixer discharge height		m	3.8
Total weight		t	62
Outline dimension(L*W*H)		m	40*19*18.5
Loading			skip hoist
Weighing accuracy	Aggregate	%	±2
	Powder	%	±1
	Water	%	±1
	Additive	%	±1

---
