| Product Specification |
| Hardware Performance | Module | AMZ043W02RPGE |
| Display Size | 4.3" TFT LCD |
| Resolution | 480X272 |
| Colors | 260000 |
| Brightness | 300 cd/m2 |
| Backlight | LED |
| LED life | 20000 hours |
| Touch screen | 4-wire resistive touch screen touch screen(Surface hardness 4H) |
| CPU | 32-bit 600MHz ARM9 built-in |
| Memory | AMZ043W02RPGE:16Mbyte SPI Nor Flash |
| RTC | Real-time clock built-in |
| Ethernet | Unsupported |
| Save power failure data | AMZ043W02RPGE:Not supported |
| USB | A USB2.0 Device port |
| Program download Mode | USB,SD card |
| U disk | Not supported |
| Communication port | AMZ043W02RPGE:COM1:RS232
AMZ043W02RPGD:C0M1:RS485 |
| Electrical Specifications | Maximum power consumption | <2W |
| The rated voltage | AC 10-30V |
| Power protection | +/-2KV lightning surge protection capability |
| The allowed loss of power | <5ms |
| CE&ROHS | Comply with EN61000-6-2:2005, EN61000-6-4:2007 standards;Lightning surge +/ -2kV, EFT: +/ -4kV;Electrostatic contact discharge +/-8KV;Electrostatic air discharge +/-10KV. |
| Environmental Specifications | Operating temperature | -20ºC~60ºC |
| Storage temperature | -30ºC~70ºC |
| Environmental humidity | 10~90%RH(non-condensing) |
| Vibration | 10-25Hz(X, Y, Z direction, 2g/30 min) |
| Cooling way | Natural air cooling |
| The Other Parameters | Protection grade | The front panel conforms to IP65 (with flat plate cabinet installation), and the rear panel conforms to IP20 |
| Display Active Area | 95mmX54mm |
| Panel Cutout | 130mmX78mm |
| Overall dimensions | 138mmX86mm |
| The weight | 168g |
