WZ40-28 Backhoe loader
Contact：Richie Shi
Title :Sales Manager
Mobile：+86 13356718553(whatsApp/wechat)
Email: richieshi@belladintelligent.com
Main fature
1-The use of high-reliability hydraulic torque converter and Gearbox to provide super power,
aggravated the smooth and high reliability of the dedicated bridge walking
2-Combine the excavator and the loader into one, and one
machine can do more. Fully equipped with all the functions of small excavators and loaders, it is more suitable for operating in a narrow space, convenient and flexible, and working efficiency is increased by more than 30 %.
3-Mining, loading function all lead control, light and flexible, high operating efficiency.
4.-Humanized design of rotating vibration absorber seat, fully steel-molded glass cab, wider vision, more comfortable driving.
5-Excavate the lateral sliding mechanism device to make the excavation operation more extensive and more efficient.
6-The design of the front flip cover greatly improves the maintenance of the entire machine.
7-A variety of accessories can be selected to complete a
variety of construction operations. For use in municipal administration, construction, water Conservancy, highways, tap water,
power supply, gardens and other departments, can be engaged in agricultural construction, pipeline laying, cable laying,
landscaping and other operations
Product Description
Specification
Main specifications:
Overall Operating Weight
| 8200kg
|
Loader Bucket Capacity
| 1.0m3
|
Rated Load Weight
| 2500KG
|
Backhoe Capacity
| 0.3 m3
|
L*W*H(mm)
| 6230×2365×3752
|
Wheel base
| 2200mm
|
Min. Ground Clearance
| 300mm
|
Breakout Force
| 38KN
|
Bucket Dumping Height
| 2650mm
|
Bucket Dumping Distance
| 1025mm
|
Digging Depth
| 52mm
|
Max. Digging Depth
| 4085mm
|
Swing Angle of Excavator Grab
| 190°
|
Max. Pulling Force
| 39KN
|
Engine
|
Model
| Cummins engine//Yuchai YC4A105Z-T20//
|
Type
| turbocharging four-stroke
|
Cylinder-Inside Diameter*Stroke
| 4-105
|
Rated Power
| 74KW/100HP
|
Rated Speed
| 2400r/min
|
Min. Fuel Consumption
| 235g/kw.h
|
Max.Torque
| 310NM
|
Displacement
| 4.3L
|
Transmission Gearbox
|
Type
| Fixed Shaft Power Transmission
|
Oil Pressure of Clutch
| 1373Kpa-1569 Kpa
|
Gears
| Two Gears Ahead, Two Gears Astern
|
Max.Speed
| 22Km/h
|
Steering System
|
Model of Steering Device
| BZZ5-250
|
Steering Angle
| ±36 o
|
Min. turning radius
| 6581mm
|
Pressure of the system
| 12Mpa
|
Hydraulic System
|
Digging Power of Excavator Grab
| 46.5KN
|
Digging Power of Dipper
| 31KN
|
Bucket Lifting Time
| 5.4S
|
Bucket Lowering Time
| 3.1S
|
Bucket Discharge Time
| 2.0S
|
Brake System
|
Service Brake
| Air Over Oil Caliper Brake
|
External Type
|
Self-regulation
|
Self-balance
|
Emergency Brake
| Operation Power Implementing brake
|
Manual Operation Power Terminating Brake
|
Axle
|
Manufacturer
| Feicheng Axle Factory
|
Main Transmission Type
| Double Reduction
|
Final Reducer
| Single Stage Final Reducer
|
Tyre
|
Model
| 14-17.5/19.5L-24
|
Pressure of Front wheel
| 0.22 Mpa
|
Pressure of Back Wheel
| 0.22 Mpa
|
Optionals:
|
|
Cummins 74kw engine
|
|
Air conditioner
| Waranty:12months
|
Pallet fork
| Delivery time:25days
|
4in1 bucket
| Package: 1unit in 40feet container
|
Break hammer
| 2units in 40feet container is also OK
|
Loader quick hitch
|
|
Excavator quick hitch
|
|
Pre-pipe for break hammer
|
|
Wood/grass gripper
|
|
Product Features
The engine adopts environmental-friendly YC4A105Z-T20 Stage Ⅱ engine Ⅱ ,(Cummins QSB3.9-C100-31 EU Stage Ⅲ or Stage V can be option )featuring strong power, reliable performance, and high efficiency and energy-saving.
It’s equipped Shaft Powershift / Electric control, featuring good power matching, stable motion, and more powerful operations. The structures ease the repairs and maintenances.It suitable for diversified severe industrial and mining conditions and realizes faster movement.
The pipelines are arranged smoothly and the oil tank layout is adjusted to improve the system reliability and maintainability.
The optimized 2,650mm dumping height, guarantees the excellent loading performance and ensures the carrying of higher torsional torque, featuring extensive loading/unloading scope and high efficiency. The automatic leveling function of the bucket and the 11.9 ± 0.15 s total cycle time, reduce the driver’s labor strength.
The optimized 2,200mm wheelbase guarantees outstanding site adaptability and flexibility and the operation stability to fulfill the loading and unloading operations with ease.
Multiple working devices are at your choice.
Application
Application for small and medium-sized gravel yards, mixing stations, small coal mines, farms, ranches, and urban construction and road construction.
Packing & Delivery
2 units of WZ30-25 backhoe loaders in one 20feet and one 40feet HQ container.
2 units of BLD776 backhoe loaders in one 40feet HQ container.
