Product Details
Product Description
Product Description
Wire range: 2 - 10mm².
Conductor length: 100 - 10000mm (other lengths can be customized).
Capacity: 15 seconds/piece.
Crimping force: 40KN (can be customized).
Power supply: 220V 50/60Hz.
Air pressure: 0.5Mpa - 0.7Mpa.
Weight: about 7000kg.
Dimensions: 13000x1500x2600mm.
Inspections: wire feeding inspection, edge pressure inspection, shielding mesh inspection, air pressure inspection, visual inspection, insertion force detection, terminal tension output inspection.
Applied applicators: OTP applicator, European mechanical applicator and pneumatic applicator.
Functions: automatic wire cutting, pre-wearing of rubber parts, automatic feeding and installation of sheaths and components, stripping of conductor sheaths, crimping of shielding rings, stripping and crimping of internal conductors, terminal crimping, crimping of shielding rings, and sheath blocking.
Fully automated equipment can be customized according to customer samples
>>
