| Model | 4M210-06 | 4M220-06 | 4M210-08 | 4M220-08 | |
| Fluid | Air | ||||
| Acting | Internal pilot air solenoid valve | ||||
| Valve type | 5/2 way solenoid valve | ||||
| Orifice size | 14mm2 | 16mm2 | |||
| Lubrication | No required | ||||
| Port size | In=out=G1/8'' | In=out=G1/4'' | |||
| Protective class | IP65 | ||||
| Pressure range | 0.15-0.8MPa(21~1145Psi) | ||||
| Proof pressure | 1.2MPa(170psi) | ||||
| Material of body | Aluminum Alloy | ||||
| Temperature | -5℃~60℃ | ||||
| Response speed | <0.05s | ||||
