Waste Indutrial Oil Refinery Equipment/Mini Oil Refinery Distillation Plant

Product Description

Product Description Application
JZC waste oil distillation machine heat the waste oil to (from 110ºC to 350ºC) different temperature under high vacuum condition, making Hydrocarbon molecules break out, and re-order combination, forming diesel oil, lubricating base oil etc. JZC machine is very suitable for the small oil refinery company, also for the small oil company who want to make the oil by self.
Product Parameters
Features and Advantages
I.The vacuum system uses the roots pump as the main pump and the rotary vane vacuum pump as the primary pump. Fast start-up, large
pumping speed, stable performance, and high ultimate vacuum of less than 5Pa.
II.Double horizontal vacuum separators, combined with Duplex-Stereo film evaporation technology
III.Strong ability to remove impurities: ultra-large area cylindrical precision filter element, with high filtration accuracy, easy installation and replacement.
IV.Low-load heating: Adopt advanced internal and external double-tube heat radiation indirect heating technology.
V.Automatic control to realize unattended, safe and stable working.
VI.Safety interlock protection for oil pump, vacuum pump, heater,keep safely working
VII.Low noise, easy operation, long maintenance interval, low energy consumption, low operating cost
VIII.It can be used together with the insulation oil regeneration device, which has the effect of decoloring, deacidification, deoxidation and removing
free carbon and other harmful substances from the oil.
Most 3 obvious advantages of our JZC equipment compared with competitors
1. The warranty period of our equipment is 2 years, and other companies usually only have 1 year.
2.Distillation tank has insulation layer, which has energy-saving effect 3.The cooler is made of stainless steel, which has a longer life.

JZC machine workflow Main system:1. Catalyst system; 2. Chemistry treatment system;3. Heating system;4. Distilling system;5. Cooling system;6. Vacuum system;7. Degasification system;8. Oil storage system ;9. Oil additive mixing system;10. Control system;11. Oil refinery System;12. Odor/Waste Gas Treatment system
This is a simple flow chart of JZC. If you want a more detailed flow chart, please contact Sales Manager AmyQian
Working Steps Of The Machine( Omitted version )
There are five steps from waste oil to base oil.
1.Use press paper filter device filter impurities in waste oil
2.The waste oil leads to the waste oil mixing tank, heat the waste oil to 60-80 ºC and then mix it with sodium hydroxide. When sodium hydroxide is mixed with waste oil, a chemical reaction will occur, flocculation and precipitation.
3.Use press paper filter device filter waste oil again, the waste oil then flows to the distillation tank.
4. Set the temperature, let the distillation tank heat to the set temperature, and distill out water vapor and oil vapor. The distillation temperature reaches 80-110ºC, and water is distilled.The distillation temperature reaches 120-210ºC, and Gasoline and diesel is distilled. The distillation temperature reaches 220-290ºC, and light base oil is distilled. The distillation temperature reaches 300-350ºC, and heavy base oil (Viscosity≥SN150 ) is distilled.
5. The oil is then condensed through a cooler condenser,condensation from vapor state to liquid state. This step is actually the operation of employees opening different valves and pumps. There is no difficulty in operation. Emphasize that the machine comes with a collection tank that can separate different types of oil. Oil Parameters After Treatment

Final Product	Ratio Percentages	Distillation Temperature	Vacuum Value
Water	2%	80ºC-110ºC	-0.098
Gasoline and diesel	8%	120ºC-210ºC	500Pa
Light base oil	40%	220ºC-290ºC	50-500 Pa
Heavy base oil	45%	300ºC-350ºC	50-500 Pa
Oil Resicudal	5%
Total	100%

Detailed Photos
Project Show
JZC machine has been sold to the following countries:
Honduras, Panama, Russia, Turkmenistan, Kyrgyzstan, Greece, Ghana, Cameroon, Tanzania, Cambodia, Malaysia, Indonesia, Senegal, Mexico, Uzbekistan, Lebanon, Sierra Leone, Cô te d 'Ivoire, Mongolia and so on.

Customer Visit Our Company
Certifications
Company Prrofile :
CHONGQING NAKIN ELECTROMECHANICAL CO.LTD.is a professional mechanism manufacturer (oil purifier) from Chongqing China.The company has a 3000 square meter production workshop with more than 40 staffs and engineers. The company is joint-stock high-tech enterprise, after ten years of development, company has grown into a comprehensive enterprise, engaging in vacuum oil purifier producing, filter element producing, and Imp&Exp trading. NAKIN oil purifier and filter are widely applied in projects of transformer substation, electric department, steel structure, bridge, auto, railway, aviation, chemicals, petroleum etc. The products are exported to more than 30 countries and areas, such as Europe, America, Middle East, Southeast Asia and so on. The product gets the good reputation from the dealer and end user.

FAQ Q1. What are the heating methods of the machine?
A: The conventional heating method of JZC is electric heating. If you need to customize the burner heating mode, we can also customize it for you. Q2. How about the Installation of the machine?
A: About installation, the installation of the machine is modular and sample.If we send engineer , buyer need to be responsible for engineer's round-trip airfare, visa, accommodation and his salary 100 dollars /day. With the installation instructions,buyer can also install by themselves. Our Engineers can talk with customers in English video to teach how to install and use the machine.Whether engineers are needed or not depends on the customers themselves.
Q3. What is your terms of payment?
A: Generally, we use T/T, 30% in advance, balance pay after the machine finish.
Q4. How about your delivery time?
A: Generally, JZC-1 (1 ton/day) need 35 workings days to finish. The specific delivery time depends on the items and the quantity of your order.
Q5. Can you customized goods for us?
A: Yes, we can customized according to your flow requirements, the brand requirements of parts used in the machine........
Q6. If you have any inspection or test for your goods before delivery?
A: Yes, we do the inspection and test before finished goods.
Q7. Can we visit your factory?
A: Yes, we warmly welcome your visiting, and can pick up you at airport or train station.

---
