Industrial Water Process Dissolved Ozone Electrode Oxygen Ozone Analyzer

Product Description

CS6520 Process Dissolved Ozone Sensor stainless steel body Range: 0 to 2.000 mg/L 0 to 20.00 mg/L Work Temp: 0 - 50C Translation: 2A/ppm Length: 120mm Φ13mm Cable: 3m Connector:Terminals

CS6530 Dissolved Ozone Sensor Principle:Potentiostatic Range:0 - 2.000 mg/L, 0 - 20.00 mg/L Resolution:0.001 mg/L, 0.01 mg/L Temperature range:0 - 70 C Pressure:0 -6 bar Optimum Flow Rate:25-100 L/h Shell material:Glass+PP Thread Cap:PG13.5 Electrode dimensions:12x120mm Cable length:5m Connector:Terminals IP rated:IP68

CS6730 Dissolved Ozone Sensor Principle:Potentiostatic Range:0 - 2.000 mg/L, 0 - 20.00 mg/L Resolution:0.001 mg/L, 0.01 mg/L Temperature range:0 - 70ºC Pressure:0 -6 bar Optimum Flow Rate:25-100 L/h Shell material:Glass+PP Thread Cap:3/4″ NPT Electrode dimensions:30x160mm Cable length:5m Connector:Terminals IP rated:IP68

Dissolved Ozone Controller / Transmitter It is suitable for online measurement and control of water disinfection in the fields of tap water industry, swimming pool, water park, ozone generator, container disinfection in food and beverage industry, etc.Note that the generator that produces ozone disinfection by electrolytic water is not applicable.
128 * 64 dot-matrix LCD display, switchable in Chinese and English, IP65 protection level, all-weather stable operation
simple menu design, simple and convenient operation, graphical prompt, beautiful and clear interface
software digital filtering is adjustable, with enhanced hardware resistance to interference, making measurements more stable and adapted to complex industrial environments
global access power supply 85~260VAC, but also customized DC model 18 to 36 V D C
RS-485 digital interface, MODBUS-RTU communication protocol, read and write two-way communication, can achieve remote complete control of the instrument

ozone	measuring range	0.00~20mg/L.00
	resolution ratio	0.01 mg/L
	Measurement accuracy (electronic unit)	±0.10 mg/L
temperature	measuring range	-10.0~130.0ºC
	resolution ratio	0.1ºC
	Measurement accuracy (electronic unit)	±0.3ºC
	Temperature input	PT1000
	temperature compensation	Automatic / manual
Transfer current	Output, type	Two roads of 4~20 mA (the corresponding range can be set)
	Current accuracy	±1% F .S
	output loading	less-than 500Ω
control	Functional relay	One (which can be set to the cleaning or alarm function)
	Switch amount relay	2 SPST relays
	load capacity	2.5A 230VAC
data transmission	interface	All-way RS485 isolation voltage is 2500Vrms
	protocol	MODBUS-RTU (read-write two-way communication)
Other parameters	working power supply	85~260VAC or 18~36VDC (optional before order)
	working temperature	0~60ºC
	Operating humidity	Relative humidity was <90%
	levels of protection	IP65
	way to install	Disk installation
	outline dimension	(H×W×D) 108×108×132 mm
	Open hole size	92.5 * 92.5 mm (positive tolerance)

---
