| Main Parameter | Display modes: B , B/B ,4B ,B+M ,CFM ,B+CFM ,PDI , B+PDI ,PW |
| Gray scale: 256 levels, |
| 5 levels image optimization |
| THI imaging technology; |
| Rich image processing technology, for instance frames average, view angle, edge enhance, Gamma ,etc |
| CN,EN,RUS,POR,ESP,FR,DE 7 kinds languages; |
| Display penetration depth 1~400mm |
| Dynamic range: 80~280dB adjustable; |
| Main Parameter | Application mode OB,GYN, Small organ, Urology, Pediatric, Cardiac etc; |
| Preset the parameter depend on scanning organ; |
| IMT automatic measurement and display results; |
| 15 kinds of pseudo color; |
| Support guide line of biopsy puncture; |
| Built-in 120G soild state drive ,make the storage safer and more reliable; |
| Support frequency conversion range: 2MHz~12MHz (depend on probe type |
| Built-in editable report page ; |
| Main Parameter | Gain control: 8 segments TGC and overall gain can be adjusted respectively; |
| Focus position: dynamic electron focusing |
| Image processing: Level 5 image optimization, edge enhancement, frame average, Line average, focus optimization, noise suppression, Gamma correction, closing curve, contrast |
| Image annotation: alphanumeric input, adjustable annotation arrows, labels and comments, body markers, patient and hospital ids, etc. |
| Image storage: image storage, video storage. Movie playback, solid,state disk storage capacity ≥128G; |
| Appearance size: 590mm×885mm×1205mmm (length × width × height) |
