Professional Making 20 Inch Plastic Water Filter Housing Mold

US$6,000.00-15,000.00 1 Set (MOQ)

Basic Info.

Model NO.

J210243

Mould Cavity

Single Cavity

Plastic Material

Process Combination Type

Single-Process Mode

Application

Home Use

Runner

Cold Runner

Design Software

Installation

Fixed

Certification

ISO

Standard

DME

Customized

Mould Runner System

for Cold or Hot Runner

Size

According to Customers Requirement

Mould Design Software

Ug, Proe, Solidworks CAD, etc

Mould Base

S50c/C45

Mould Quality Control

Professional QC in House

Mould Operating Mode

Automatically by CNC

Heat Treatment

Nitriding

T1 Sample

60 Days

Mould Report

7-10days

Aftersale

Yes

Transport Package

High Quality Wooden Case

Specification

DME, HASCO, LKM, etc

Trademark

JSLMOULD

Origin

Huangyan, Taizhou, China

HS Code

8480719090

Production Capacity

500sets/Year

Product Description

Professional Making 20 Inch Plastic Water Filter Housing Mould
1. Provide 3D design
2. Mould Steel/hardness: 718 HRC34-38
3. OEM service
4. Mould life: 500000shots
For the Q/C of mould, there are 3 steps:
1. Mould Material Q/C
- Mould Steel Checking(Hardness, flaw detection)
- Mould Standard Spare Parts Checking(hardness, size, flaw checking)
2. Mould Making Process Q/C
- design checking (part design, mould design, mould engineering drawing)
- checking each part of mould's size after machining, according to 2D drawing
- mould testing(check mould running condition)
3. Check with customer's requirement again before mould shipping.

Product Name	Professional Making 20 Inch Plastic Water Filter Housing Mold
Product material	pp/pc
Core&Cavity Steel	718
Steel hardness:	HRC35-38
Mould Standard	DME
Cavity Number	1
Injection System	side gate
Ejector System	Ejector pin
Cycle Time	30 s
Tooling lead time	60 days
Mould life	500000 times
Quality assurance	ISO9001

Our Advantage	1.High quality
	2.Reasonable price
	3.On time delivery
	4.Good After-sale service
	5.Strict quality control
	6.All the mould are automotic.

Offer you	In-time response on letters, telephone calls or fax
	In-time supply the quotation and mould designs
	In-time communication on the technical points
	In-time sending pictures for the mould machining progress and mould finishing schedule
	In-time mould test and sample delivery
	In-time mould delivery

For more information please contact us.
