Ck6150 Tornos High Precision Speed Performance Heavy Duty Automatic Metal Horizontal Parallel Cutting Turning Center Tool Flat Bed CNC Lathe Machine

Product Description

Product Description
Ck6150 Tornos High Precision Speed Performance Heavy Duty Automatic Metal Horizontal Parallel Cutting Turning Center Tool Flat Bed CNC Lathe Machine
we are the most professional in making flat bed cnc lathe Product Parameters
Application :
CK series CNC Lathe machine is an economical, practical type machine tools with high quality.
It has a very wide use which is suitable for internal and external turning, tapering, circular arc, thread, boring, reaming of axis and disk workpiece. It also can achieve non-circular curve machining. You can choose the CNC system and optional accessories according to your requirements.

Features :
Big torque ,high precision spindle
Hydraulic shift ,easy operate
Z axis feed is directly connected which has high transmission accuracy and high positioning accuracy
Vertical 4 position electric toolpost with high positioning accuracy

Standard configuration:
GSK control system
Manual chuck
Manual tailstock

Optional Configuration :
Siemens or Fanuc system
Hydraulic chuck
Hydraulic tailstock
Electric turret /Hydraulic turret
Automatic chip conveyor

SPECIFICATIONS	SPECIFICATIONS	Units	CK6140	CK6150
	Swing over bed	mm	400	500
	Swing over cross slide	mm	210	260
	Distance between centers	mm	750/1000/1500/2000	750/1000/1500/2000
	Spindle bore	mm	52(Optional 80)	52(Optional 80)
	Spindle bore taper	-	MT6	MT6
	Spindle nose type	-	C6	C6
	Spindle speed steps	-	Manual 2 steps	Manual 2 steps
	Spindle speed range	rpm	L:100-500 H:500-1800	L:100-500 H:500-1800
			(Optional 90-1800 stepless)	(Optional 90-1800 stepless)
	Turret/tool post	-	Electric 4 position	Electric 4 position
	Tool size	mm	25 x 25	25 x 25
	X axis travel	mm	230	280
	Z axis travel	mm	750/1000/1500/2000	750/1000/1500/2000
	X axis rapid traverse	mm/min	6000	6000
	Z axis rapid traverse	mm/min	8000	8000
	Tailstock quill diameter	mm	65	65
	Tailstock quill taper	-	MT4	MT5
	Tailstock quill travel	mm	130	130
	Main spindle motor	kw	4	5.5
	Coolant pump motor	kw	0.09	0.09
	Weight for 750	kg	1700	1800
	Weight for 1000	kg	1800	1900
	Weight for 1500	kg	1900	2000
	Weight for 2000	kg	2000	2100
	Dimension for 750	mm	2200x1650x1700	2200x1700x1750
	Dimension for 1000	mm	2500x1650x1700	2500x1700x1750
	Dimension for 1500	mm	3000x1650x1700	3000x1700x1750
	Dimension for 2000	mm	3500x1650x1700	3500x1700x1750

Realistic photos
Detailed Photos

Company Profile

FAQ
1: Where is your company A: Our company is located in Tengzhou City, Shandong Province.2: What about your warranty?A: Warranty is one year. During warranty time, if the parts are damaged because of Nonhuman factors, we will send new replaced parts for free3: How do you offer after-sale service?A: We usually offer technical support online by wechat or whatsapp. Customer describe the problems and send videos and pictures, our technician will help to solve the problems4. What is your standard package? A: Our package is export standard plywood case with pallet.5: What's the Payment Terms? A: T/T, 30% initial payment when order, 70% balance payment before shipment; 6: What's the MOQ? A: 1 set.
