Cisco Catalyst 9300 48-port PoE+, Network Essentials, Cisco 9300 switch C9300-48P-E
1. Cisco Catalyst 9300 48-port PoE+, Network Essentials,
5. Other Related Part code :C9300L-24T-4G-E C9300L-24P-4G-E
6. 1 year Warranty
Highest wireless scale for Wi-Fi 6 and 802.11ac Wave 2 access points supported on a single switch with select models.
Catalyst 9300 and Catalyst 9300L/LM models are based on the Cisco UADP 2.0 Application-Specific Integrated Circuit (ASIC) with programmable pipeline and micro-engine capabilities, along with template-based, configurable allocation of Layer 2 and Layer 3 forwarding, Access Control Lists (ACLs), and Quality of Service (QoS) entries.
Catalyst 9300X models are based on UADP 2.0sec ASIC which adds line rate support for Crypto, including 100G hardware-based IPsec.
x86 CPU complex with 8-GB memory, and 16 GB of flash and external USB 3.0 SSD pluggable storage slot (delivering up to 240GB of storage with an option SSD drive) to host containers. C9300X models support 16GB of memory.
USB 2.0 slot to load system images and set configurations.
Up to 1 TBps of local stackable switching bandwidth with Catalyst 9300X models.
Flexible and dense uplink offerings with 100G, 40G, 25G, Multigigabit, 10G, and 1G as fixed or modular uplinks.
Easy transition from 40G to 100G and 10G to 25G with dual-rate optics.
Flexible downlink options with 25G, 10G and 1G Copper and Fiber as well as the densest Multigigabit links.
With a mix of copper (1G up to 10G) and fiber (1G up to 25G) supported in a single stack, multiple flexible deployment scenarios are enabled, including 2-Tier, 3-Tier and Hybrid architectures.
The Cisco Catalyst 9300 Series is made up of nineteen modular uplink switch models and fourteen fixed uplink switch models.
| Part Number | Description |
| C9300X-48HX-E | Catalyst 9300 48-port 10G/mGig copper with modular uplink, UPOE+, Network Essentials |
| C9300X-48HX-A | Catalyst 9300 48-port 10G/mGig copper with modular uplink, UPOE+, Network Advantage |
| C9300X-48TX-E | Catalyst 9300 48-port 10G/mGig copper with modular uplink, data only, Network Essentials |
| C9300X-48TX-A | Catalyst 9300 48-port 10G/mGig copper with modular uplink, data only, Network Advantage |
| C9300X-48HXN-E | Catalyst 9300 36-port 5G/mGig, 12-port 10G copper with modular uplink, UPOE+, Network Essentials |
| C9300X-48HXN-A | Catalyst 9300 36-port 5G/mGig, 12-port 10G copper with modular uplink, UPOE+, Network Advantage |
| C9300X-24HX-E | Catalyst 9300 24-port 10G/mGig copper with modular uplink, UPOE+, Network Essentials |
| C9300X-24HX-A | Catalyst 9300 24-port 10G/mGig copper with modular uplink, UPOE+, Network Advantage |
| C9300X-12Y-E | Catalyst 9300 12-port 25G/10G/1G SFP28 with modular uplinks, Network Essentials |
| C9300X-12Y-A | Catalyst 9300 12-port 25G/10G/1G SFP28 with modular uplinks, Network Advantage |
| C9300X-24Y-E | Catalyst 9300 24-port 25G/10G/1G SFP28 with modular uplinks, Network Essentials |
| C9300X-24Y-A | Catalyst 9300 24-port 25G/10G/1G SFP28 with modular uplinks, Network Advantage |
| C9300-24T-E | Catalyst 9300 24-port 1G copper with modular uplinks, data only, Network Essentials |
| C9300-24T-A | Catalyst 9300 24-port 1G copper with modular uplinks, data only, Network Advantage |
| C9300-24P-E | Catalyst 9300 24-port 1G copper with modular uplinks, PoE+, Network Essentials |
| C9300-24P-A | Catalyst 9300 24-port 1G copper with modular uplinks, PoE+, Network Advantage |
| C9300-24U-E | Catalyst 9300 24-port 1G copper with modular uplinks, UPOE, Network Essentials |
| C9300-24U-A | Catalyst 9300 24-port 1G copper with modular uplinks, UPOE, Network Advantage |
| C9300-24UB-E | Catalyst 9300 higher scale 24-port 1G copper with modular uplinks, UPOE, Network Essentials |
| C9300-24UB-A | Catalyst 9300 higher scale 24-port 1G copper with modular uplinks, UPOE, Network Advantage |
| C9300-24U-E-UL | Catalyst 9300 24-port 1G copper with modular uplinks, UPOE, Network Advantage |
| (Compatible with UL1069 Standard*) |
| C9300-24U-A-UL | Catalyst 9300 24-port 1G copper with modular uplinks, UPOE, Network Advantage |
| (Compatible with UL1069 Standard*) |
| C9300-24H-E | Catalyst 9300 24-port 1G copper with modular uplinks, UPOE+, Network Essentials |
| C9300-24H-A | Catalyst 9300 24-port 1G copper with modular uplinks, UPOE+, Network Advantage |
| C9300-24UX-E | Catalyst 9300 24-port 10G/mGig copper with modular uplink, UPOE, Network Essentials |
| C9300-24UX-A | Catalyst 9300 24-port 10G/mGig copper with modular uplink, UPOE, Network Advantage |
| C9300-24UXB-E | Catalyst 9300 higher scale 24-port 10G/mGig copper with modular uplink, UPOE, Network Essentials |
| C9300-24UXB-A | Catalyst 9300 higher scale 24-port 10G/mGig copper with modular uplink, UPOE, Network Advantage |
| C9300-48T-E | Catalyst 9300 48-port 1G copper with modular uplinks, data only, Network Essentials |
| C9300-48T-A | Catalyst 9300 48-port 1G copper with modular uplinks, data only, Network Advantage |
| C9300-48P-E | Catalyst 9300 48-port 1G copper with modular uplinks, PoE+, Network Essentials |
| C9300-48P-A | Catalyst 9300 48-port 1G copper with modular uplinks, PoE+, Network Advantage |
| C9300-48U-E | Catalyst 9300 48-port 1G copper with modular uplinks, UPOE, Network Essentials |
| C9300-48U-A | Catalyst 9300 48-port 1G copper with modular uplinks, UPOE, Network Advantage |
| C9300-48UB-E | Catalyst 9300 higher scale 48-port 1G copper with modular uplinks, UPOE, Network Essentials |
| C9300-48UB-A | Catalyst 9300 higher scale 48-port 1G copper with modular uplinks, UPOE, Network Advantage |
| C9300-48U-E-UL | Catalyst 9300 48-port 1G copper with modular uplinks, UPOE, Network Essentials |
| (Compatible with UL1069 Standard*) |
| C9300-48U-A-UL | Catalyst 9300 48-port 1G copper with modular uplinks, UPOE, Network Advantage |
| (Compatible with UL1069 Standard*) |
| C9300-48H-E | Catalyst 9300 48-port 1G copper with modular uplinks, UPOE+, Network Essentials |
| C9300-48H-A | Catalyst 9300 48-port 1G copper with modular uplinks, UPOE+, Network Advantage |
| C9300-48UXM-E | Catalyst 9300 48-port 2.5G (12 10G/mGig) copper with modular uplinks, UPOE, Network Essentials |
| C9300-48UXM-A | Catalyst 9300 48-port 2.5G (12 10G/mGig) copper with modular uplinks, UPOE, Network Advantage |
| C9300-48UN-E | Catalyst 9300 48-port 5G copper with modular uplinks, UPOE, Network Essentials |
| C9300-48UN-A | Catalyst 9300 48-port 5G copper with modular uplinks, UPOE, Network Advantage |
| C9300-24S-E | Catalyst 9300 24-port 1G SFP with modular uplinks, Network Essentials |
| C9300-24S-A | Catalyst 9300 24-port 1G SFP with modular uplinks, Network Advantage |
| C9300-48S-E | Catalyst 9300 48-port 1G SFP with modular uplinks, Network Essentials |
| C9300-48S-A | Catalyst 9300 48-port 1G SFP with modular uplinks, Network Advantage |
| C9300L-24T-4G-E | Catalyst 9300 24-port 1G copper, with fixed 4x1G SFP uplinks, data only, Network Essentials |
| C9300L-24T-4G-A | Catalyst 9300 24-port 1G copper, with fixed 4x1G SFP uplinks, data only, Network Advantage |
| C9300L-24P-4G-E | Catalyst 9300 24-port 1G copper, with fixed 4x1G SFP uplinks, PoE+, Network Essentials |
| C9300L-24P-4G-A | Catalyst 9300 24-port 1G copper, with fixed 4x1G SFP uplinks, PoE+, Network Advantage |
| C9300L-48T-4G-E | Catalyst 9300 48-port 1G copper, with fixed 4x1G SFP uplinks, data only, Network Essentials |
| C9300L-48T-4G-A | Catalyst 9300 48-port 1G copper, with fixed 4x1G SFP uplinks, data only, Network Advantage |
| C9300L-48P-4G-E | Catalyst 9300 48-port 1G copper, with fixed 4x1G SFP uplinks, PoE+, Network Essentials |
| C9300L-48P-4G-A | Catalyst 9300 48-port 1G copper with fixed 4x1G SFP uplinks, PoE+, Network Advantage |
| C9300L-48PF-4G-E | Catalyst 9300 48-port 1G copper with fixed 4x1G SFP uplinks, PoE+, Network Essentials |
| C9300L-48PF-4G-A | Catalyst 9300 48-port 1G copper with fixed 4x1G SFP uplinks, PoE+, Network Advantage |
| C9300L-24T-4X-E | Catalyst 9300 24-port 1G copper with fixed 4x10G/1G SFP+ uplinks, data only, Network Essentials |
| C9300L-24T-4X-A | Catalyst 9300 24-port 1G copper with fixed 4x10G/1G SFP+ uplinks, data only, Network Advantage |
| C9300L-24T-4X-M | Catalyst 9300 24-port 1G copper with fixed 4x10G/1G SFP+ uplinks, data only, Meraki Advanced or Enterprise |
| C9300L-24P-4X-E | Catalyst 9300 24-port 1G copper with fixed 4x10G/1G SFP+ uplinks, PoE+, Network Essentials |
| C9300L-24P-4X-A | Catalyst 9300 24-port 1G copper with fixed 4x10G/1G SFP+ uplinks, PoE+, Network Advantage |
| C9300L-24UXG-4X-E | Catalyst 9300 24-port 8XmGig (100M/1G/2.5G/5G/10G) + 16x 10M/100M/1G copper with fixed 4x10G/1G SFP+ uplinks, UPOE, Network Essentials |
| C9300L-24UXG-4X-A | Catalyst 9300 24-port 8XmGig (100M/1G/2.5G/5G/10G) + 16x 10M/100M/1G copper with fixed 4x10G/1G SFP+ uplinks, UPOE, Network Advantage |
| C9300L-48T-4X-E | Catalyst 9300 48-port 1G copper with fixed 4x10G/1G SFP+ uplinks, data only, Network Essentials |
| C9300L-48T-4X-A | Catalyst 9300 48-port 1G copper with fixed 4x10G/1G SFP+ uplinks, data only, Network Advantage |
| C9300L-48T-4X-M | Catalyst 9300 48-port 1G copper with fixed 4x10G/1G SFP+ uplinks, data only, Meraki Advanced or Enterprise |
| C9300L-48P-4X-E | Catalyst 9300 48-port 1G copper with fixed 4x10G/1G SFP+ uplinks, PoE+, Network Essentials |
| C9300L-48P-4X-A | Catalyst 9300 48-port 1G copper with fixed 4x10G/1G SFP+ uplinks, PoE+, Network Advantage |
| C9300L-48PF-4X-E | Catalyst 9300 48-port 1G copper with fixed 4x10G/1G SFP+ uplinks, full PoE+, Network Essentials |
| C9300L-48PF-4X-A | Catalyst 9300 48-port 1G copper with fixed 4x10G/1G SFP+ uplinks, full PoE+, Network Advantage |
| C9300L-48UXG-4X-E | Catalyst 9300 48-port fixed uplinks UPOE, 12x mGig (100M/1G/2.5G/5G/10G) + 36x 10M/100M/1G copper, 4x 10G uplinks, Network Essentials |
| C9300L-48UXG-4X-A | Catalyst 9300 48-port 12x mGig (100M/1G/2.5G/5G/10G) + 36x 10M/100M/1G copper with fixed 4x 10G/1G SFP+ uplinks, UPOE, Network Advantage |
| C9300L-24UXG-2Q-E | Catalyst 9300 24-port 8x mGig (100M/1G/2.5G/5G/10G) + 16x 10M/100M/1G copper with fixed 2x 40G QSFP uplinks, UPOE, Network Essentials |
| C9300L-24UXG-2Q-A | Catalyst 9300 24-port 8x mGig (100M/1G/2.5G/5G/10G) + 16x 10M/100M/1G copper with fixed 2x 40G QSFP uplinks, UPOE, Network Advantage |
| C9300L-48UXG-2Q-E | Catalyst 9300 48-port 12x mGig (100M/1G/2.5G/5G/10G) + 36x 10M/100M/1G copper with fixed 2x 40G QSFP uplinks, UPOE, Network Essentials |
| C9300L-48UXG-2Q-A | Catalyst 9300 48-port 12x mGig (100M/1G/2.5G/5G/10G) + 36x 10M/100M/1G copper with fixed 2x 40G QSFP uplinks, UPOE, Network Advantage |
| C9300LM-48UX-4Y-E | Catalyst 9300 mini 48-port UPOE, 8-port 10G Multigigabit copper, 40-port 1G, 4x 25G uplinks, Network Essentials |
| C9300LM-48UX-4Y-A | Catalyst 9300 mini 48-port UPOE, 8-port 10G Multigigabit copper, 40-port 1G, 4x 25G uplinks, Network Advantage |
| C9300LM-48U-4Y-E | Catalyst 9300 mini 48-port 1G copper, UPOE, 4x 25G uplinks, Network Essentials |
| C9300LM-48U-4Y-A | Catalyst 9300 mini 48-port 1G copper, UPOE, 4x 25G uplinks, Network Advantage |
| C9300LM-48T-4Y-E | Catalyst 9300 mini 48-port 1G copper, data, 4x 25G uplinks, Network Essentials |
| C9300LM-48T-4Y-A | Catalyst 9300 mini 48-port 1G copper, data, 4x 25G uplinks, Network Advantage |
| C9300LM-24U-4Y-E | Catalyst 9300 mini 24-port 1G copper, UPOE, 4x 25G uplinks, Network Essentials |
| C9300LM-24U-4Y-A | Catalyst 9300 mini 24-port 1G copper, UPOE, 4x 25G uplinks, Network Advantage |
