China Manufacturer High Speed Plastic Corrugated Pipe Forming Machine / Equipment

US$10,600.00-11,200.00 1 Set (MOQ)

Basic Info.

Model NO.
GS-55-4
Screw No.
Single-screw
Automation
Automatic
Computerized
Computerized
Certification
CE
Customized
Customized
Condition
New
After-sales Service
Video
Cooling Method
Water-Cooling
Speed
5-30m/Min
Suitable Material
PP/PE/PVC/PA/EVA
Transport Package
Wooden Box Packing
Specification
2200*800*1200
Trademark
GZSJ
Origin
Panan Zhejiang
HS Code
8477409000
Production Capacity
1500 /Year

Product Description


Details :
Model GS series High Speed Corrugated Pipe Production Line ( Gear Drive) has adopted PLC control system, which is complete functions easy operation , has linkage functions. When machine power cut off happens in the process of the production , it can effectively protect the safety of equipment and mould. It uses a whole closed track to transfer moulds, stable operation and high production efficiency guarantee the fastest production , the speed can reaching 3 meters per minute. Also this kind of production line can equipped with one mould with double chambers , it's can save a considerable cost for customers.
Main Technical Parameters :
Item No Motor Power
(KW)
Production Speed
(m/min)
Mould Perimeter
(mm)
Diameter (mm) Extruder Total Power
(KW)
GS-14-2 1.1 5-25 1978 φ7---φ14 φ45---φ50 25
GS-55-3 4 5-30 3051 φ10---φ55 φ50---φ65 30
GS-55-4 4 5-30 4068 φ10---φ55 φ65---φ80 30-50

Notes: The specification are subject to change without prior notice.
Applications :
This production line is suitable for such production : auto-mobile wire harness tube , electric wire conduit , drain pipe of washing machine , air-condition tube , telescopic tube , medical breathing tube and other kinds of tubular products etc....
PACKAGE
Workshop
FAQ Q: Are you trading company or manufacturer ?A: We are factory. Q: How long is your delivery time?A: Generally it is 20-45 days after receiving the deposit.The special time need discussing the new delivery date . Q: How do you make the quotation for clients?
A:Please offer the following information, so we can give you price and our advice as manufacturer:
1. Type of pipe you want to produce.
2. Pipe diameters.
3. Raw material and its types
If you can send us photos of your samples, it would be highly appreciated. Q: What is your terms of payment ?A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us .
