Hydraulic Automatic Cutting Machine for Mattress Cushion

Product Description

Product Description
Hydraulic Automatic Cutting Machine for Mattress Cushion
Felt Cutting Machine
Travel Head Die Cutting Machine
Product Description
Usage and Characteristics
1. Hydraulic Automatic Cutting Machine for Mattress Cushion is designed for large plants to continuously cut non-metal materials(such as felt, leather, rubber and cloth) in large batch with the help of molding cutting die.
2. PLC computer touch screen are adopted to control procedures, servo motor driver conveying system, ensure feeding accuracy, stable running speed.
3. The main machine is controlled by four-column guiding, double-crank balancing, four-column blocking fine-adjustment mechanism and hydraulic control system, which guarantee the speed and accuracy of die cutting machine.
4.All movable connecting parts are equipped with central oil supply automatic lubricating device, which can raise abrasive resisitance.
5. The input and output of materials are conveyed on the conveying belt, and the die cutting of materials is also automatically completed on the conveying belt.
6. A safety light curtain can be optionally provided for the inlet and outlet of the machine's cutting zone in order to ensure operator's personal safety.
7. A photoelectric pneumatic deviation rectifier is used to ensure accurate operation position of conveyor belt.
8. Cutting die or mould fixed on a movable head can accurately move leftward and rightward when controlled by a servo motor.
9. Products of special specifications can be customized.
Main Technical Data(Customizable)
Hydraulic Automatic Cutting Machine for Mattress Cushion
Model
KTC/S
Maximum Cutting Force
40T
50T
Cutting Area
1600*500mm1600*700mm
Motor Power
4.0KW
5.5KW
Tension Distance25-175mm25-175mm
Travel Head
500*500mm
700*700mm

Machine Advantages:
1. Hydraulic Automatic Cutting Machine for Mattress Cushion controlled by PLC, electric box, human-computer interface, easy to operate.
2. The main machine adopts double-crank connecting rod balance, four-columns, which makes sure that the cutting depth at every cutting position is the same.
3. The travel head slows down when it presses down near the material, which makes sure that there is hardly any size difference between the uppermost layer and lowest layer of the materials.
4. Conveyor belt system facilitates the material input and products output.
5. Auto waste remover system enlarges the machine application range.

Machine Pictures
Hydraulic Automatic Cutting Machine for Mattress Cushion Front Side
Hydraulic Automatic Cutting Machine for Mattress Cushion Back Side
Application For Cutting Machine:
Hydraulic Automatic Cutting Machine
Customer Visit & Exhibition
Packaging & Shipping
Hydraulic Automatic Cutting Machine for Mattress Cushion
Inner Package: Protective Film, etc
Outside Package: Plywood Case
Machines well packed with protective film and loaded in plywood case or export container;English version operation manual and technical data;One-Year-Period wear parts;Tool kit
Our Services
Hydraulic Automatic Cutting Machine for Mattress Cushion
Company Information
CE & ISO Certificates:
Hydraulic Automatic Cutting Machine for Mattress Cushion
1. Are you a trading company or a manufacturer?
We are a manufacturer with strong export capability.
2. Where is your factory?
We are in Yancheng city, three and a half hours' drive away from Shanghai, China.
3. Do you have individual research and development department?
Yes, we have. We believes in technology and market oriented research. Every year, we will work out a number of solutions to actual onsite application problems and develop brand new machines for our customers.
Shoud you have any new ideas about our machines, pls feel free to contact us! We are sure to make your ideas into designs. Our goal is to work together with our customers to solve every onsite problems, to realize better material finishing/processing effect and to be our customers' think tank.
4. How can I trust your quality?
We have CE and ISO certificates. They enhance quality control throughout the manufacturing of our machines.We have professional QCs. For each step of our machine production, there will be a team of QCs responsible for the inspection. Until the item passes all the inspections can it go to the following step.At the end of the machine assembling, a series of testings will be conducted. Unless the machine passes all the testings, we will not make delivery.We guarantee our machines with one-year warranty. Usually, our customers use our machines for 5 years, 8 years and even 10 years.Throughout the lifespan of our machines, the spare parts replacement will be at cost price.5. How to operate the machine? We have not used such a machine before. We just want to expand our business and start a new line.
Pls do not worry! Almost 50% of our overseas customers were in the same situation when buying first of our machines. We have skillful and experienced follow up service staff who have worked out a whole package of solutions catering to the need of our customers like you. Besides, we have a team of technicians available for overseas machine installing, testing and operation instruction.
