Product Details
Product Description
Product Description
4-layers Sintered Titanium Wire Mesh Filter Plate is an innovative material consisting of four layers of titanium stretched mesh delicately sintered together. The titanium tensile mesh is used as the basic structure, and the thin sheet-like mesh structure made of pure titanium material gives the mesh material excellent strength and excellent corrosion resistance. This material cleverly stacks multiple layers of titanium stretched mesh and connects them tightly by high-temperature sintering process to form a strong structure of 4-layers Sintered Titanium Wire Mesh Filter Plate.
Each layer of titanium tensile mesh plays an important role in the four-layer sintered titanium mesh. The first layer of tensile mesh provides the strength and corrosion resistance of the foundation, laying a solid foundation for the overall structure. The superposition of the second layer and the third layer increases the strength and stability of the material, enabling the sintered titanium mesh to withstand greater load and pressure. The introduction of the fourth layer further enhances the impact resistance and durability of the overall structure.
Parameter
Material: GR1 titanium
Length*Width: 230mm*240mm
Mesh number: 10 mesh
Layers: 4 layers
Technique: use 4 pieces of titanium expanded mesh by sintering
Features
1. High filtration efficiency: The multi-layer structure provides a larger filtration area, effectively captures tiny particles and suspended solids, and achieves excellent solid-liquid separation and gas-solid separation.
2. Excellent mechanical strength: The multi-layer titanium tensile mesh is superimposed and sintered, which has excellent mechanical strength and pressure resistance, and is suitable for high pressure and large flow working conditions.
3. Strong corrosion resistance: Titanium itself has excellent corrosion resistance, and can operate stably for a long time in corrosive media, resisting the erosion of acid-base solutions, salt water and high-temperature environments.
4. Wide temperature adaptability: It has good thermal stability, can work in a wide temperature range, and is suitable for high and low temperature environments.
5. Easy to clean and maintain: The flat surface and open mesh structure are easy to clean and maintain, and the filtration efficiency can be restored by simple flushing or back-blowing to prolong the service life.
1. Material properties:
Stainless steel multi-layer sintered wire mesh: Stainless steel multi-layer sintered wire mesh is usually made of stainless steel, which has good mechanical strength and corrosion resistance. Stainless steel materials are suitable for a wide range of industrial applications, and are resistant to acids, alkalis, and high temperatures.
Titanium multilayer sintered mesh: Titanium multilayer sintered mesh is made of titanium material, which has light weight, high strength and excellent corrosion resistance. Titanium materials are widely used in chemical, marine and other fields, and can resist strong acids, strong alkalis and other corrosive media.
2. Density and weight:
Stainless steel multi-layer sintered wire mesh: Due to the high density of stainless steel, stainless steel multi-layer sintered wire mesh is relatively heavy.
Titanium multi-layer sintered mesh: The density of titanium is low, so the titanium multi-layer sintered mesh is relatively light, which helps to reduce equipment load and reduce transportation costs.
3. Corrosion resistance:
Stainless steel multi-layer sintered mesh: stainless steel material has good corrosion resistance and can resist the erosion of many corrosive media. But in extremely corrosive environments, such as strong acids, strong bases, and high salt concentrations, corrosion may occur.
Titanium multi-layer sintered mesh: Titanium material has excellent corrosion resistance and can resist the erosion of various acid, alkali, salt and other corrosive media. Titanium is a material widely used in corrosive environments such as the marine and chemical industries.
4. Filtration accuracy:
Stainless steel multi-layer sintered mesh: The micropore size of stainless steel multi-layer sintered mesh is relatively large, and the filtration accuracy may be low. For applications requiring coarser filtration.
Titanium multi-layer sintered mesh: The micropore size of titanium multi-layer sintered mesh can be adjusted according to requirements, and has high filtration accuracy. For applications requiring finer filtration.
Applications
1. Chemical industry: In the operation of liquid-solid separation and gas-solid separation, the sintered titanium mesh filter plate efficiently filters tiny particles and impurities to ensure product quality and production efficiency.
2. Oil and natural gas industry: Sintered titanium mesh filter plate is corrosion-resistant and suitable for high-pressure and high-temperature environments. It is used in oil extraction, oil refining and natural gas treatment to remove particles and impurities.
3. Food processing industry: Sintered titanium mesh filter plate removes suspended solids, microorganisms and impurities, and is suitable for filtration, clarification and bacterial barrier in food and beverage production.
4. Pharmaceutical and bioengineering: Sintered titanium mesh filter plate provides reliable microbial barrier and particle filtration, suitable for pharmaceutical production, bioreactors and biosafety laboratories.
5. Electronics industry: Sintered titanium mesh filter plates are used in air filtration systems in electronics manufacturing to remove pollutants and particles and protect sensitive electronic components.
6. Sewage treatment: Sintered titanium mesh filter plate is corrosion-resistant and has high filtration efficiency, suitable for industrial water treatment, sewage treatment and water recycling systems.
7. Automotive and aerospace: Sintered titanium mesh filter plates are used for air filtration and purification, preventing pollutants from entering critical systems and maintaining a clean environment.
8. Mining and metallurgical industry: Sintered titanium mesh filter plate has corrosion resistance and mechanical strength, and is used for solid-liquid separation, gas-solid separation and metal powder filtration.
9. Stone processing and ceramic industry: Sintered titanium mesh filter plate is used for particle separation and filtration to improve product quality and surface finish.
>>
