Ecoographix Digital Robot Book Binding Stitching Machine Perfect Binder

Negotiable 1 set (MOQ)

Basic Info.

Model NO.
Robot 800A
Classification of Financial Binding Machine
Full-automatic
Classification of Wire Binding Machine
34 Hole
Thickness
20-50mm
No. of Clamps
4
Max. Mechanical Speed
1600c/H
Book Block Length (a)
140-400mm
Book Block Thickness (C)
3-50mm
Cover Length (D)
140-450mm
Transport Package
Standard Exporting Wooden Box
Specification
4086*2212*1600 mm
Trademark
EcooGraphix
Origin
China
HS Code
8440109
Production Capacity
1000 Sets/Year

Product Description

Digital Print-on-Demand Perfect Binder
Digital Robot 2000A is our latest innovation of 'off-line' book binding solution for print-on-demand printing. It features on fully automatic adjustments through touch screen, short changeover time for varied binding formats, exchangeable EVA gluing tank and PUR gluing tank (option), which makes Digital Robot 2000A an ideal post-press solution for short run and print-on-demand digital printing.
Digital Robot 2000A is available for inline connection with digital three-knife trimmer and digital stacker in order to achieve a fully automatic perfect binding line. Through which, even very short runs can be produced quickly and in an economical way.
Features Quick Setup and High Automation: All setups can be done automatically just by inputting data into the touch screen or via scanning the barcode information of the book block and the cover. Fast Automatic Changeover: Automatic job changeover can be accurately completed in as short as 10s for changing book thickness and book formats at the fastest speed. Large Binding Compatibility: Digital Robot 2000A offers strong binding for different kinds of book blocks, such as loose-sheet book block, cold-glued book blocks, sewn book blocks, etc. Optional PUR Gluing Station: Changeover between EVA and PUR gluing application systems can be easily finished in just a few minutes. Soft Book Lay-down System: The special designed soft book lay-down system can maximally protect the just bound book spine from any slight deformation.
Technical data
4) Technical Data
Machine Model Digital Robot 2000A Binder
No. of Clamps 4
Max. Mechanical Speed 1600c/h
Book Block Length (a) 140-400mm
Book Block Width (b) 120-270mm
Book Block Thickness (c) 3-50mm
Cover Length (d) 140-450mm
Cover Width (e)
Machine Dimensions (L*W*H)
280-590mm
4086*2212*1600 mm
Machine Model DT-30 Three-knife Trimmer
Untrimmed Book Size Min.: 145x105mm
Max: 370x330mm
Trimmed Book Size Min.: 140x100mm
Max: 360x300mm
Trim Thickness 3-50mm
Mechanical Speed 15 Cycles/ Min
Power Required 8.5kw
Machine Weight 2000KG
Machine Model Digital Stacker
Max. Speed of Stacking 900 stacks/h
Spine Length 140-320mm
Book Width 120-280mm
Stacking Height Max.:50mm
Power Required 0.9kw
Machine Weight 100kg
Machine Dimensions (L*W*H) 1150*700*870mm
Max. Speed of Stacking 900 stacks/h

Certificate
FAQ:
1. What are your main products ?
We offer full range of printing materials covering prepress, prrssroom and postpress machines and consumables. We serve hard around clock for dealers and end users who are in either packaging industry or book printing industry. We mainly supply the Prepress CTP machines,Printing materials,Digital Label Printers, Digital Book Binders,Digital Foil Stamping and Die Cutting machine,UV Inkjet Printer,Paper Slitting and Rewinding machines ,Paper Box/Cup Forming machinesand so on.
2. Where is your factory ?
Our factory is located in Shenzhen city , which is about 1.5 hour by train from Shanghai.You are warmly welcomed to visit our factory!
3. What is your warranty ?
One to Three years.
4. What is the Lead Time?
Usually 20-30 days, and we will try our best to meet your demands.
5. Is there any options,please?
Yes, we provide Nordson Nozzle PUR Application System:
Nordson PUR melter (MiniPUR Plus) + Nordson PUR Automatic Gun (SB60-Bod), but not for free.
6. What about the Installation and after-sales technician support?
Our engineer can go to help the installation and provide the necessary training. The buyer should take the round air plane tickets and service charge and the local accommodation cost. Any problems or questions,we will be at your disposal 7x24 hours.
