Radius 10 M Distributor-Concrete Placing Boom - 10 M

Product Description

This hydraulic climbing type is ideal for high rise buildings, bridges and dams. Placed on tubular columns, they can climb up automatically with self-climbing system, enabling the concrete to be delivered exceptionally fast and cost-effectively.
1: Fully hydraulic control and can slewing 360°
2: Balance valves are products of oilcontrol company of Italy and the solenoid directional valves are products of Rexroth Company of Germany
3: Main electric components are products of the world-renowned brand such as Omron or Schneider.
4: Two modes of operation: Radio remote control and cable remote control
Parameter data :

Model		PB10AS(HG10AS) ( Optional: rise 400mm or 900mm)
Max horizontal reach of the placing boom(m)		10
Working area M2		314
Stationary height(m)		2.2
Slewing range(°)		360
Mode of operation		Manual
Arms length(m)	1st section	4.5
	2nd section	5.5
Delivery pipe dimension(mm)		DN125
Wind speed(m/s)		≤ 13.8
Working temperature(ºC)		-20~48
Total weight(with counterweight) (kg)		1900
Counter weight (kg)		600
Max lifting weight(kg)		1300

TRUEMAX provided and provides every day design, construction and installation of mixer and batching plants for some of the most important construction projects around the world, the product range includes a wide variety of solution of concrete machinery:
concrete batching plant
concrete truck mixer,
concrete placing boom,
concrete pump,
concrete line pump,
concrete truck-mounted pump.


Our Service
Faster speed of response of service
Modern transportation network of railway and aviation,
make sure that all spare parts got delivered in time.

Apart from supplying only the best quality products, we
also have available our technical and management solutions.
Our service teams always ready to provide
expertise to you. Truemax is ready to provide you with a full range of services.

Best service effect to win your
satisfaction and trust
We continue to work for guests providing customized
system solutions and provide best support and services.
Because of the formidable technical team, we have
provided high quality tour service to all guests.

---
