Horizontal and vertical turret milling machine X6328C X6328C-1 X6328A X6328A-1

Product Description

MILLING MACHINE FEATURES:
X6328C Horizontal and Vertical Drilling Milling Machine is suitable to volume production, individual production, machining department,tools and repairing department. It can using accessories, such universal milling head, swivel table and dividing head, which can expand the range of machining. The vertical spindle can roate at a high speed with wide range.
This machine not only has the performance of general universal milling machine, but also machining and measure workpiece at the same time when installing DRO device, so make sure the machining quality of workpiece, and reduce labour intensity and raise labour productivity.
The manual feed on X Y Z, table auto feed on X Y, while can rapid feed on X Y.
Turret milling machine
Hardened and ground guideways
Table automatic feed on X,Y direction by gear driven
SPECIFICATIONS:

SPECIFICATION	UNIT	X6328C	X6328C-1	X6328A		X6328A-1
Table size	mm	1200X280
Table travel(X. Y. Z)	mm	620/260/400
T-slots(NO: /width/pitch)	mm	3/14/70
Spindle nose to table surface	mm	90-490	70-470	60-460		95-495
Distance between horizontal spindle and table surface	mm	0-280
Spindle speed range	r/min	8steps, 115-1750 (V)	Standard: 16steps80~5520 Optional: variable speed	8 steps, 115~1750		Standard: 16steps80~5520 Optional: variable speed
		12steps, 45-1350 (H)
Spindle taper	-	MT4(V)	R8/IS040(V)	MT4(V)		R8/IS040(V)
		IS040(H)
Automatic feed of spindle		0.04/0.08/0.15
Table feed	mm/min	30-855			13-265
Take-off and landing platform feed	mm/min	9-270			manual
Distance between horizontal spindle and ram surface	mm	215
Main motor power	kw	1.85/1.5(V)	2.2(V)		0.85/1.5(V)	2.2(V)
		2.2(H)
Rapid motor power	kw	0.75
Overall size	mm	1750x1450x2200
Net weight	kg	1420			1380

Contact Us:

Andy Wang TENGZHOU HOTON MACHINERY CO.,LTD Tel:0086 632 5633796 MP:0086 13506328892 hotonmachinery.en.made-in-china.com

Company Profile:

Tengzhou Hoton Machinery Co.,LTD was established in 2006, and is the professional machine manufacturer in China. There are 480 workers, of whom 60 are engineers. It has an area of 46,000 square meter, general assets 30,000,000. It has a store of 350 equipments and the good ability of products design & manufacturing. It has export quality permit from 2007, and has export right given by the State Foreign Economic Trade Committee in 2008.

The leading products: "Hoton" series of CNC machines, Lathes, Milling machines, Drilling machines,Grinding machines, Saws, Sheet metal machines, Metal forming machines, and other machine accessories.Some products have national patent.It has fourteen series, over eighty models by itself. It has the ability of making 100,000 sets every year. All the products are designed perfectly and has high quality high performance and low price, and the excellent quality guarantee system. The products have past ISO9001 and CE certification since 2009. The products have been export to five continents, over forty countries and areas. It resulted to the attraction of client abroad and home, the quickly promotion of products sale.

Tengzhou Hoton Machinery Co.,Ltd. is willing to make common progress and developments with all the customers. Quality first,Constantly perfecting skills.

---
