DETA dryflex 6VEL105 6V105Ah DETA Battery

Product Details

Product Description

Product Description
DETA dryflex 6VEL105 6V105Ah DETA Battery
DETA dryflex 6VEL105 6V105Ah DETA Battery
DETA battery 2VEG300, 6VEL105 product information specification
Features of silver sequoia (DETA) 6VEL105 product
Product model
6VEL105
Product specification
Type of energy storage system independent
Energy storage system technology Lead acid (AGM)
Yinshan battery product parameter table
Electrical performance parameters
Number of cells per cell
3/set
Nominal voltage
6 V
Nominal capacity
23.1Ah@1hr 79.5Ah@5hr 87.7Ah@10hr 105Ah@20hr
Internal resistance
5 mΩ
Design life
12 years
Temperature parameters
Charging temperature - 0~+50 ℃
Discharge temperature - 20~+60 ℃
General parameters
Dimensions (length * width * height)
194x170x212 mm
Weight
16.5 Kg
Constant current discharge characteristic: A (25 ℃)
Fixed voltage/time (V) 0.17 hr 0.25 hr 0.5 hr 1 hr 2 hr 3 hr 4 hr 5 hr 8 hr 10 hr 20 hr
1.6 V 185.4 145 95.4 55.9 33.4 23.1 19.1 16.1 11 9.12 5.5
1.65 V 176.4 142.1 93.8 55.6 33.2 23 19 16 10.9 9.03 5.3
1.7 V 170.1 139.8 93 55.1 32.9 22.8 18.9 15.9 10.8 8.95 5.15
1.75 V 158.9 134.7 93.2 54.6 32.7 22.7 18.8 15.7 10.7 8.86 5
1.8 V 146.6 125.6 92.5 53.3 32.1 22.1 18.3 15.4 10.6 8.77 4.7
Product features of Yinshan (DETA) 6OPZV 300
Product model
6OPzV300
Product specification
Type of energy storage system independent
Energy storage system technology Lead acid (colloid)
Yinshan battery product parameter table
Electrical performance parameters
Nominal voltage
2 V
Maximum discharge current
2400 A
Maximum charging current
90 A
Internal resistance
1 mΩ
Design life
20 years
Temperature parameters
Charging temperature - 0~+40 ℃
Discharge temperature - 20~+50 ℃
Storage temperature - 15~+40 ℃
General parameters
Dimensions (length * width * height)
145x206x390 mm
Weight
26 Kg
Shell material: acrylonitrile-butadiene-styrene
Top cover material: acrylonitrile-butadiene-styrene
Constant current discharge characteristic: A (25 ℃)
Fixed voltage/time (V) 0.17 hr 0.25 hr 0.5 hr 1 hr 2 hr 3 hr 5 hr 8 hr 10 hr 20 hr
1.85 V 256.3 233.2 183.2 135.1 91.3 70.1 47.8 33.33 28.1 14.89
1.8 V 315.3 282.3 214.2 152.2 100.1 76.3 51.7 35.74 30 15.9
1.75 V 373.4 316.3 228.2 158.2 103.1 78 52.7 36.34 30.5 16.17
1.7 V 418.4 344.3 241.2 164.2 106.1 79.6 53.5 36.84 30.8 16.32
1.65 V 449.4 364.4 251.3 168.2 108.1 81.1 54.3 37.24 31.1 16.48
1.6 V 470.5 377.4 257.3 171.2 109.1 82 54.9 37.54 31 16.43
Constant power discharge characteristic: W (25 ℃)
Fixed voltage/time (V) 0.17 hr 0.25 hr 0.5 hr 1 hr 2 hr 3 hr 5 hr 8 hr 10 hr 20 hr
1.85 V 476.5 438.4 350.4 260.3 177.2 137.1 94.2 66.17 55.96 29.8
1.8 V 576.6 522.5 404.4 291.3 194.2 148.1 101.1 70.67 59.66 31.78
1.75 V 669.7 577.6 426.4 301.3 198.2 151.2 103.1 71.77 60.46 32.2
1.7 V 738.7 620.6 447.4 311.3 202.2 153.2 104.1 72.47 61.06 32.52
1.65 V 778.8 645.6 460.5 317.3 205.2 155.2 105.1 73.17 61.56 32.79
1.6 V 799.8 658.7 467.5 321.3 207.2 157.2 106.1 73.57 61.96 33
Yinshan Battery (Shandong) Co., Ltd.&Beijing Lusheng Power Equipment Co., Ltd
12VEG65F 2VEH200 4OPzV200 12VEL80
12VEG85F 2VEH260 5OPzV250 12VEL100
12VEG100F 2VEH300 6OPzV300 6VEL105
12VEG180 2VEH400 5OPzV350 6VEL160
2VEG100 2VEH500 6OPzV420 6VEL200
2VEG200 2VEH600 7OPzV490 2VEL200
2VEG260 2VEH800 6OPzV600 2VEL300
2VEG300 2VEH1000 8OPzV800 2VEL350
2VEG400 2VEH1200 10OPzV1000 2VEL400
2VEG500 2VEH1500 12OPzV1200 2VEL455
2VEG600 2VEH2000 12OPzV1500 2VEL515
2VEG800 2VEH3000 16OPzV2000 2VEL560
2VEG1000 20OPzV2500 2VEL600
2VEG1200 24OPzV3000 2VEL650
2VEG1500 2VEL800
2VEG2000 2VEL1000
2VEG3000 2VEL1500

---
