| Negotiable | 1 Set (MOQ) |
| Performance And Characteristics | |
| Application Honeycomb paper is eco-friendly and cost effective alternative for plastic bubble wrap cushioning.It is easy to stretch,more soft and flexible,provide cushion protect without surface scratch.Finished products from this machine can be used to pack fruits,flowers,ceramics, glassware,etc. Machine features 1.This machine is suitable for die cutting honeycomb paper,wrapping paper, shock-absorbing paper, kraft paper,fish net paper from 70g to 100g. 2.The unwinding,cutting and rewinding in one process. 3.Main motor equipped with Inverter (Delta Brand) for speed regulation. 4. Computer with PLC (Delta brand) controlled, touch screen (Weinview brand). 5. Main machine body with thicker iron plate 6. Tension controlled automatically by magnetic powder brake and clutch,both is 10 kgs. 7. Automatic meter counting device,automatically stop after it reaches the length you set. 8. Pneumatic cylinder to control the cutting module up and down. 9. Optional parts: Web Guiding system | |
| Machine Model | SD-PH600 |
| Max material width | 515mm (508mm/20inch and 380mm/15inch width most) |
| Machine working speed | 0-200m/min adjustable |
| Unwinding diameter | Max. 1200mm |
| Rewinding diameter | Max. 300mm |
| Unwinding roll weight | Max. 1 Ton |
| Unwinding shaft | 3" inflatable air shaft |
| Rewinding shaft | 1"/1.5"/2"/3" air shaft (choose either one,usually is 1.5") |
| Machine size | 2300*1350*1300mm (LxWxH) |
| Machine weight | 1500 KG |
| Machine power | 3 KW |
| Power supply | 380V 3 Phase,50hz or as customer requirement |
