Diesel Version China Trailer Concrete Pump Delivery Pump Machine

Product Description

Trailer concrete pump HBT9018K concrete pump machine for sale
1. By comprehensively incorporating switch-over control technology, the extraction and control of switch-over signal is totally done by hydraulic pressure, avoiding the unreliability brought by frequent electrical contact and harsh environment and reducing customers' later maintenance cost.
2. By adopting exclusive invariable reversing buffering technology in the industry, the pump displacement keeps unchanged during pumping and reversing and the main system unloads in low pressure, which thoroughly avoid such problems as long reversing time, great reversing impact and low service life of pump caused by frequent change of displacement during traditional reversing.
3. The use of equivalent bending moment design ensures uniform force, reliable sealing and greatly prolongs the service life of bearing ring, spectacle wear plate and cutting ring. The feature of unilateral wear makes the theoretical service life of rock valve once higher than that of S-valve.

Description			Unit	Parameter value
Overall performance	Overall dimensions		mm	6482×2100×2886
	Total curb mass		kg	7400
	Concrete delivery value		m3/h	115/60
	Max. output pressure		Mpa	18
	Pulling speed		km/h	Three-level road 8km/h
				Road above two-level 16km/h
	Delivery distance(vertical/horizontal)		m	250/1000
	Hopper capacity/filling height		m3/mm	0.6/1370
	Concrete slump range		mm	80-230
	Concrete delivery cylinder diameter/stroke		mm	230/1600
Power system	Main motor (diesel engine)	Model		BF6M1013
		Rated power	kw/r/min	186/2100
		Manufacturer		DEUTZ
Hydraulic system	Type			Open type
	Pressure of hydraulic system		Mpa	32
	Main oil pump	Model and type		280
		Rated working flow	L/min	560
		Manufacturer		KAWASAKI
	Pumping oil cylinder diameter /stroke		mm	170/1600
	Capacity of hydraulic oil tank		L	600
Mixing system				Large torque at low speed

---
