OA500 Bare Finished Network Floor Steel Raised Floor

Product Description

Detailed Photos

OA panel is made of steel plate, top to be SPCC material,bottom to be ST14 materials.After pan formed and joined together by resistance welding, the panel is coated with epoxy paint, then infilled with light cement.
Feature
All-steel structure,nice loading capacity
Excellent fire resistance ability
Good dimension accurace,panel can be interchangeable
Wire trucking system
A workstation can be easily and quickly relocated with cable management without disruption. Convenient for connecting wire at any point without cutting floor. Suitable for all kinds of plug socket terminals.Adjustable wire-connected location.
Feature
OA access floro system effectively reduces energy cost and improves inside air quality,makes it to be green office environment.

Product Parameters

Type	Size	Concentrated		Impact Load	Ultimate Load	Uniform Load	Rolling Load/N
International	mm	N	KG	N	N	N/M2	10Times	10000Times
OA668	500X500X28	≥2990	≥300	670	≥8890	≥12500	2215	1548
OA800	500X500X28	≥3596	≥366	670	≥10799	≥19796	2959	2215
OA1000	500X500X28	≥4498	≥458	670	≥13494	≥23294	3596	2959

Company Profile MAJET is a leading manufacturer and exporter in China, supplying access floor system, data center products, underfloor air conditioning, underfloor wiring and accessories. We have over 60,000 square meters plant and 200 workers and around 34 years experience in this industry.
Application *commercial office buildings
*data center,computer room
*educational facilities
*casions
*clean room
*libraries
Production process
Packaging & Shipping Panels are packaged in pallet, wraped with plastic film.
Quality control
FAQ Q1.What is your MOQ?
A: 100pieces each type

Q2.What is the loading quantity in one 20GP?
A:1100-1500pieces,depending on the raised floor type.

Q3.When is your delivery time?
A: 30days after receiving the prepayment.

Q4.What is your package?
A:packed in wooden pallet,covered with plastic film.

Q5.What is your payment term?
A:T/T,L/C,Western Union.

---
