| IP69K Waterproof LED Warning Lamp (MODEL:DF-J-CY24) |
| LED:24x1W High Intensity LED's |
| Maximum Power Consumption: 28Watts |
| Maximum Luminous intensity:700 cd(0°~Night) |
| Waterproof Rating:100% IP69K(100KPa) |
| Color Temperature: 1800K (Amber) |
| Flash frequency:2 Hz ≤F ≤ 4 Hz |
| Approval:ECE R65/ R10(EMC) /SAE J845 Class 1 |
| Light Color: Amber/ Red/ Blue (option) |
| Alarm way:6 + Switch scintillation and rotation mode through external control line |
| Flash Mode: --RPM187*1 --RPM125*1 --FPM222*1 --FPM125*1 --FPM125*2 --FPM125*3 |
| Visibility: 360 Degree |
| Material:Die-casting Aluminum Alloy Base + PC Lampshade + Aluminum Alloy Heat Dissipation Column |
| Optics Inner Lens:Hybrid Wide-Angle Reflector *3 |
| Mounting: Magnetic Base or Fixed Bolt (option) |
| Load Dump: DC14+67V(Td400mS) 5pulses |
| Operating temperature: -40ºC to +65ºC |
| Warranty: 3 years |
| Shockproof: 10G |
| Free Operating Voltage::DC10-32V(DC48V Custom-made) |
| Weight::500g |
| Dimensions:117.5(H) x112(D) mm |
| Widely used in construction vehicles (excavators, logging machines, rollers bulldozers, cranes, mining vehicles, agricultural machinery, ambulances, forklifts) special vehicles, off-road vehicles, ATV and other vehicle lighting and mining field patrols and other special or mobile environment lighting etc. |
