Product Details
Product Description
Product Description
30% Denser Briquettes with Advanced Roller Design
30% Denser Briquettes with Advanced Roller Design is also known as: strong ball pressing machine, mineral powder ball pressing machine, roller ball pressing machine, goose egg forming machine, and so on. The ball pressing machine is mainly used for making balls and briquetting of nonferrous and Ferrous ore powder, smelting directly into the furnace, and improving the added value. All metallurgical industry waste and auxiliary materials that need to be fed into the furnace require a ball press to complete. For example, dust removal ash, pool mud, oxide skin, steel slag, iron concentrate powder, aluminum ash powder, silicon manganese ore powder, and so on. Ball press is a device that presses powdered materials into balls.
The 30% Denser Briquettes with Advanced Roller Design is widely used to press, granulate or press the following materials, such as aluminum chips, activated carbon, aluminum oxide, Bauxite, caustic soda, charcoal, clay, coke chips, coal, Cryolite, fertilizer, plastic, limestone, pigment, urea, potassium salt, etc. Its purpose is to reduce dust, control bulk density, reuse, and improve transportation characteristics. The design of production capacity is mainly used for pelletizing materials in the dry powder pressing Pidgeon process magnesium smelting process.
30% Denser Briquettes with Advanced Roller Design Technical Parameter:
XM Series Coal Briquetting Machine
| Model | Reducer | Ratio | Roller Size(mm) | Main Shaft Speed(r/min) | Matched Power(kw) | Capacity(t/h) | Pressure Type |
| XM290 | ZQ350 | 1:31.5 | 290*200 | 12-14 | 5.5 | 0.9-1.0 | Constant Pressure |
| XM360 | ZQ350 | 1:31.5 | 360*250 | 12-14 | 7.5 | 1.5-2.0 | Constant Pressure/Hydraulic Pressure |
| XM400 | ZQ400 | 1:31.5 | 400*250 | 12-14 | 7.5 | 2.5-3.5 |
| XM430 | ZQ400 | 1:31.5 | 430*250 | 12-14 | 11 | 3.5-4.5 |
| XM500 | ZQ650 | 40.17 | 500*470 | 10-12 | 37 | 7.5-8.5 |
| XM650 | ZQ850 | 40.17 | 650*470 | 9-11 | 45 | 9-10 |
| XM750 | ZQ1000 | 40.17 | 750*570 | 9-11 | 90 | 13-14 |
| XM850 | ZQ1250 | 50 | 850*570 | 8-10 | 110 | 15-17 |
| Remarks: Above capacity is based on material specific gravity 0.8, briquette size: φ50*33mm |
| Roller material is 65Mn, high chrome alloy and 9Cr2Mo |
| According to different material adjust machine parameter to meet customer production |
KF Series Mineral Powder Briquetting Machine
| Model | Reducer | Ratio | Roller Size | Main Shaft Speed(r/min) | Matched Power(kw) | Capacity(t/h) | Pressure Type |
| KF500-371-280 | ZQ500 | 40.17 | 370*280 | 8-10 | 11 | 6.5-7.5 | Constant Pressure/Hydraulic Pressure |
| KF650-500-300 | ZQ650 | 40.17 | 500*300 | 8-10 | 37 | 8.5-9.5 |
| KF850-650-300 | ZQ850 | 40.17 | 650*300 | 8-10 | 55 | 10.5-11.5 |
| KF1250-750-350 | ZS1250 | 50 | 750*350 | 7-9 | 110 | 13.5-14.0 |
| KF1450-850-350 | ZS1450 | 50 | 850*350 | 7-9 | 132 | 15.0-16.0 |
| KF560-1000-350 | ZSY560 | 50 | 1000*350 | 7-9 | 150 | 17.0-20.0 |
| Remarks: Above Capacity is based on material specific gravity 2, briquette size:φ50*33mm |
| Roller material is 65Mn, high chrome alloy and 9Cr2Mo. |
| According to different material adjust machine parameter to mmet customer production |
