DELCO 24VAC Direct Acting Diaphragm Brass Solenoid Valve for Water Gas Oil

Product Description

DELCO 24VAC Direct Acting Diaphragm Brass Solenoid Valve For Water Gas Oil Product Description Direct-acting solenoid valve is a kind of industrial equipment that uses electromagnetic force to directly drive the spool to move, thus controlling the valve to open and close. Its working principle is when the coil is energized, direct-acting solenoid valve, when energized, the electromagnetic coil generates electromagnetic force to lift the closing member from the valve seat, the valve opens; when the power is off, the electromagnetic force disappears, and the spring presses the closing member to the valve seat, the valve closes. Product Features Zero Leakage Rating All Coil are CE Approved Wide Range Of Coil Voltages Low Temperature Of Operation Product Parameters

Item	24VAC Direct Acting Electric Water Solenoid Valve
Size Range	1/4" ~ 3/8"
Medium	Water, Air, Steam, Gas, Oil, etc
Temperature	NBR: -5ºC~80ºC; EPDM: -5ºC~120ºC;
Pressure	0~1.0MPa
Port Thread	NPT, BSPP, BSP, Flange
Voltage	DC-12V, 24V AC-24V, 120V, 240V/60Hz; 110V, 220v/50Hz
Tolerance	±10%
Material	Body: Brass or Stainless Steel
Application	Food & Beverage, Water & Wastewater, Ultra Pure Water, Desalination, Chemical, Textile, Pharmaceutical, Pulp & Paper, Mining, Boiler and Power Industries

Company Profile DELCO Valve is a top brand specializing in high-quality valve solutions. Our main products include a wide range of control valves, motorized valves, pneumatic valves, solenoid valves, manual valves, actuator and valve fittings. We are dedicated to offering customers reliable and efficient valve products for various industrial and commercial uses.
Our control valves provide precise regulation for accurate control of fluid flow, pressure, and temperature.
Motorized valves are valued for their easy operation and programmability.
Pneumatic valves are essential in automation systems due to their quick response and dependability.
Solenoid valves are lightweight and inexpensive.
Customers trust DELCO Valve for our exceptional quality, reliable performance, and great customer service. We will keep innovating to deliver top-notch valve solutions.

---
