Mixer Mixing Tank Fermentation Tank Chemical Mixing Equipment Device

Product Description

A stirring device is a device used for mixing. It mainly mixes solid and liquid materials through a stirrer to achieve a uniform mixing effect. Its working principle is to use mechanical energy to drive the stirrer, so that the materials in the tank are strongly moved and sheared, thereby achieving the purpose of mixing.
A stirring tank is a type of stirring device, and its structure usually includes a tank body, a stirrer, a transmission device, a bracket, a discharge port and other parts. The tank body is generally made of materials such as stainless steel and carbon steel, and has the characteristics of corrosion resistance and pressure resistance. The stirrer is designed according to different stirring methods, such as anchor stirrers, paddle stirrers, spiral blade stirrers, etc. The transmission device drives the stirrer to rotate through equipment such as a motor or a reducer.
The working principle of the stirring tank is that the transmission device transmits power to the stirrer, so that the stirrer rotates in the tank body. During the rotation of the stirrer, the materials in the tank body are strongly sheared, stirred and mixed, thereby achieving a uniform mixing effect. At the same time, the stirring tank can also be equipped with a heating device or a cooling device according to the process requirements to meet different process and production requirements.
In addition, when designing and manufacturing agitator tanks, factors such as the type, size, and speed of the agitator need to be considered. These factors affect the distribution of agitator power between overall flow and turbulent pulsation, thereby affecting the mixing effect. Therefore, when selecting and using agitator tanks, it is necessary to make reasonable designs and configurations according to specific production processes and product requirements.
In short, agitators and agitator tanks are important equipment widely used in chemical, pharmaceutical, food and other industries. A deep understanding of their structure and working principle is of great significance to improving production efficiency and product quality.

Type	kw Power	A Rated current	r/min Speed	mm Impeller diameter	N Axial thrust	kg Weight
QJB1.5/4-2500/2-36P	1.5	3.9	36	2500	1430	220
QJB3/4-2500/2-38P	3.0	7.2	38	2500	2090	220
QJB4/4-2500/2-42P	4.0	9.2	42	2500	2850	220
QJB5/4-2500/2-56P	5.0	11.9	56	2500	3820	220
QJB7.5/4-25002-63P	7.5	16.6	63	2500	5160	270
QJB1.5/4-22002-38P	1.5	3.9	38	2200	1400	210
QJB2.2/4-2200/2-42P	2.2	5.3	42	2200	1810	210
QJB3/4-2200/2-48P	3.0	7.2	48	2200	2140	210
QJB4/4-2200/2-56P	4.0	9.2	56	2200	2780	210
QJB5/4-2200/2-63P	5.0	11.9	63	2200	2960	210
OJB1.1/4-18002-38P	1.1	3	38	1800	1160	186
QJB1.5/4-18002-42P	1.5	3.9	42	1800	1480	186
QJB2.2/4-18002-48P	2.2	5.3	48	1800	1880	186
QJB3/4-1800/2-56P	3.0	7.2	56	1800	2365	186
QJB4/4-1800/2-63P	4.0	9.2	63	1800	2750	186
QJB1.5/4-16002-48P	1.5	3.9	48	1600	1320	184
QJB3/4-1600/2-56P	3.0	7.2	56	1600	2140	184
QJB4/4-1600/2-63P	4.0	9.2	63	1600	2520	184
QJB1.5/4-1400/2-48P	1.5	3.9	48	1400	1200	180
QJB2.2/4-1400/2-56P	2.2	5.3	56	1400	1640	180
QJB3/4-1400/2-63P	3.0	7.2	63	1400	2180	180
QJB2.2/4-1100/2-87P	2.2	5.3	87	1100	1970	184
QJB3/4-1100/2-115P	3.0	7.2	115	1100	2140	184
QJB4/4-1100/2-135P	4.0	9.2	135	1100	2930	184

---
