16" X24" Variable Speed Woodturning Lathe with Rotatable Headstock (MC1624VS)

Product Description

Main features:
* Electronic Inverter Variable Speed Lathe with TAIWAN DELTA brand Inverter
* Two belt ratios for high torque when turning large diameters
* Digital speed display on headstock
* Quick belt change construction headstock
* All cast iron constuction for high stability and vibration free running
* Cast iron stand with provision for a shelf
* Headstock rotates for outboard turning
* 36 Indexing Positions Function
* With Forward/Reverse running function

01) Description: 16"x24" wood lathe with Rotatable headstock

02) Motor(Input W): 1500W (with 1500W inverter)

03) No. of Speed: Variable

04) Spindle Speed: 100~1350rpm Low Speed, 220~3000rpm High Speed

05) Swing Over Bed: 408mm(16")

06) Distance Between Centers: 24.4" (620mm) or 47" (1200mm) with optional extension bed

07) Drive Spindle: M33X3.5 or 1"8RH thread

08) Headstock and Tailstock Taper:MT2#

09) Face Plate: 152mm(6")

10) Tool Rest: 300mm(12")

11) Packing Size(mm): 1130X580X550

12) NW/GW: 132/162KGS

13) Units per 20-foot container: pcs

01) Description: 16"x24" wood lathe with Rotatable headstock
02) Motor(Input W): 1500W (with 1500W inverter)
03) No. of Speed: Variable
04) Spindle Speed: 100~1350rpm Low Speed, 220~3000rpm High Speed
05) Swing Over Bed: 408mm(16")
06) Distance Between Centers: 24.4" (620mm) or 47" (1200mm) with optional extension bed
07) Drive Spindle: M33X3.5 or 1"8RH thread
08) Headstock and Tailstock Taper:MT2#
09) Face Plate: 152mm(6")
10) Tool Rest: 300mm(12")
11) Packing Size(mm): 1130X580X550
12) NW/GW: 132/162KGS
13) Units per 20-foot container: pcs
* With extra extension bed MC1624-EX+OTR available as optional accessory, which could extend the total working lenght to 1200mm(47") or Extend the bowl turning capacity to 720mm(28")

---
