X6325B Universal Turret Head Milling Machine

Product Description

X6325B Universal Turret Head Milling Machine
This kind machine is widely used in the machining workshop, with optional accessories as dividing head, rotary table, machine vice, milling chuck, etc.
Standard Accessories
Milling-cutter Mandrel
Milling-Milling machine with the middle set of taper
Milling machine mandrel(3sets)32#, 27#, 22#
Milling cutter Mandrel wrench,
Milling drawbars(2), Oil gun, wrench
Nut, Foundation screw
Optional
Vertical milling head
Dividing head
Milling chuck
Machine vice
Rotary table
Digital readout(2 dimensional or 3 dimensional)

Item	Parameter
worktable area(width*length):	350*1600mm or 350*2000mm
Max. longitudinal travel(manual)/(power)	1000/900mm or 1400/1300mm
Max. transversal travel(manual)/(power)	300/280mm
Max. vertical travel(manual)/(power)	430/400mm
T-slots(number of slot-width*pitch)	5-18*65mm
Distance from center line of horizontal spindle to table surface	30-430mm
Distance from vertical spindle nose to table	50-550mm
Horizontal Spindle taper	7: 24/ISO50
Vertical spindle taper	7: 24/ISO40
Max. swivel angle of universal rotary head	360°
Max. swivel angle of table	± 45°
Spindle speed range (horizontal/vertical)	30-1500/90-1450r/min
Table feed range (longitudinal/cross)	15-750mm/min
Table feed range(vertical)	5-250mm/min
Fast moving of table(longitudinal cross/vertical)	1920/640mm/min
Main Power(horizontal/vertical)	7.5/3KW
Feed motor	1.9/1.3kw
Motor of coolant	0.125kw
Packing Size(L× W× H)	2190× 2230× 2140mm
Net weight	3200/3500kg

WHY CHOOSE HAVEN BRAND MACHINE:
1) Hihg quality with competitive price
2) 15 years export experience
3) CE,SGS, ISO Certificated
4) OEM SERVICE AVAILABLE
5) 24 HOURS' ONLINE SERVICE (MSN,SKYPE)
6) 14 months quality warranty (after B/L date)
7) Over sea engineers available for problem shooting

Our Target: BRAND HAVEN
High quality;
Assured Delivery;
Vigorous innovation;
Efficient Cooperation;
Noblesse Oblige

---
