Oil Well Pipe with Elt Integral Drill Pipe Technology

Product Description

API 5DP Drill Pipe Seamless/Drilling Pipe Discover the innovative Oil Well Pipe with Elt Integral Drill Pipe Technology from GPE Oil Machinery Co., Ltd. Our high-quality, durable, and efficient API Drill Pipe is perfect for oil drilling. Choose from a range of sizes and lengths, including R1, R2, and R3. Experience the reliability of our OCTG Drill Pipe today!
API 5DP Drill Pipe - GPE Oil Machinery Co., Ltd
API 5DP Drill Pipe GPE Oil Machinery Co., Ltd offers high-quality API 5DP drill pipe seamless/drilling pipe that is designed to meet the standards set by API SPEC 5DP and API SPEC 7. Our drill pipes are manufactured using steel grades specified in Group 1 (Grade E) and Group 3 (Grade X-95, Grade G-105, and Grade S-135) of API SPEC 5DP.
Our drill pipe joints are provided at the same level as per customer requirements, ensuring compatibility and ease of use. The manufactured drill pipe joints strictly adhere to the provisions outlined in API SPEC 7.
Welcome to consult, we will provide the most comprehensive technical support! API 5DP Drill Pipe Seamless/Drilling Pipe Discover our high-quality oil well drill pipe with Elt integral drill pipe technology. Our durable and reliable API drill pipe is perfect for oil drilling. Choose from a range of options including R1, R2, and R3 drill pipe lengths, Nc38 and Nc31 drill pipe sizes, and doublewall pipe technology. Experience efficient and versatile drilling with our innovative bent drill pipe technology. Trust GPE Oil Machinery Co., Ltd for all your OCTG drill pipe needs.

Size (in)	Nominal Weight (1b/ft)	OD of Pipe Body		Wall Thickness of Pipe Body		Conn. Type	OD of Pin and Box		ID of Pin
		(in)	(mm)	(in)	(mm)		(in)	(mm)	(in)	(mm)
2 3/8	6.65	2 3/8	60.32	0.28	7.11	NC26 (2 3/8 IF)	3 3/8	85.7	1 3/4	44.45
2 7/8	10.4	2 7/8	73.02	0.36	9.19	NC31 (2 7/8 IF)	4 1/8	104.8	2	50.8
3 1/2	13.3	3 1/2	88.9	0.37	9.35	NC38 (3 1/2 IF)	5	127	2 7/16	61.91
3 1/2	15.5	3 1/2	88.9	0.45	11.4	NC38 (3 1/2 IF)	5	127	2 1/8	53.98
4	14	4	101.6	0.33	8.38	NC46 (4 IF)	6	154.2	3 1/4	82.55
4 1/2	16.6	4 1/2	114.3	0.34	8.56	NC40 (4 IF)	6 1/4	158.8	3	76.2
5	19.5	5	127	0.36	9.19	NC50 (4 1/2 IF)	6 5/8	168.3	3 1/4	82.55
5	25.6	5	127	0.5	12.7	5 1/2 FH	7 1/4	184.2	3 1/4	82.55
5 1/2	21.9	5 1/2	139.7	0.36	9.17	5 1/2 FH	7 1/4	184.2	3 1/2	88.9
5 1/2	24.7	5 1/2	139.7	0.42	10.54	5 1/2 FH	7 1/4	184.2	3 1/2	88.9
6 5/8	25.2	6 5/8	168.28	0.33	8.38	6 5/8 FH	8 1/4	209.6	4 3/4	120.7
6 5/8	27.7	6 5/8	168.28	0.36	9.19	6 5/8 FH	8 1/4	209.6	4 3/4	120.7

---
