10 PCS Impeller 10 HP Diesel Engine Paddle Wheel Aerator

US$950.00
5-99 Sets
US$900.00
100+ Sets

Basic Info.

Model NO.
PWA-P10
Working Method
Friction Type
Power Source
Diesel Engine
Harvesting Machinery Type
No
Fishing Method
for The Gearbox
Aquatic Products Processing Machinery
Material Handling Machinery
Fishing Gear Winch Type
Fishing Machinery
Fishing Auxiliary Machinery Type
No
Certification
CE, QS, SGS
Condition
New
Finished processing machinery
Plastic Machines and Steel Machines
Warranty
18 M
Gears Teeth
13:40,11/50,11/52,13/48t,or 11/49t
Gears Material
20crmnti
Transport Package
Standard Packing
Specification
Base on required
Trademark
Geyin
Origin
China
Production Capacity
5000/Month

Packaging & Delivery

Package Size
170.00cm * 60.00cm * 20.00cm
Package Gross Weight
100.000kg

Product Description

Name Size / weight Image Quantity set Material
 remarks
Diesel engine and gearbox 270mm•290mm•490mm/216KG 1pc Cast iron, Diesel engine customer support or we supply
Split connecting rod 5600mm/8KG
2pcs 304# SS
Pipe Impeller shaft 5500mm/21.5KG
1pc 304# SS
Impeller 660mm•660mm•200mm/2.1KG 10pcs nylon
Float 1650mm•260mm•200/5.2KG 6pcs PE
rubber connector 130mm130mm•45mm/5.5KG 2pcs Cast iron
A universal coupling 200*90*90/2.7KG 2pcs Cast iron
Bearing bracket 260mm•135mm•120mm/0.5KG 5pcs nylon
Transmission shaft 6000mm/10KG
1pc Galvanized pipe
Bearing bracket 230mm•115mm•170mm/5.6KG 1pc Cast iron
Bracket 320mm•280mm•50mm/1.5KG 1pc 304# SS
Bolt and nut 4KG 304# SS

Name Size / weight Image quantity set Material
remarks
Diesel engine and gearbox 270mm•290mm•490mm/216KG 1pc Cast iron, Diesel engine customer support
Split connecting rod 5600mm/8KG
2pcs 304# SS
Pipe Impeller shaft 5500mm/21.5KG
1pc 304# SS
Impeller 660mm•660mm•200mm/2.1KG 10pcs nylon
Float 1650mm•260mm•200/5.2KG 7pcs PE
rubber connector 130mm130mm•45mm/5.5KG 2pcs Cast iron
A universal coupling 200*90*90/2.7KG 2pcs Cast iron
Bearing bracket 260mm•135mm•120mm/0.5KG 5pcs nylon
Transmission shaft 6000mm/10KG
1pc Galvanized pipe
Bearing bracket 230mm•115mm•170mm/5.6KG 1pc Cast iron
Bracket 320mm•280mm•50mm/1.5KG 1pc 304# SS
Bolt and nut 4KG 304# SS
