Lk Potenza-III 160 Ton High Precision Servo Injection Molding Machine

Negotiable 1 Piece (MOQ)

Basic Info.

Model NO.
Potenza-III 160
Type
Preform Injection
Structure
Horizontal
Plastic Type
Thermoplastic
Plasticizing Way
Screw Type
Clamping Way
Hydraulic
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008
Transport Package
Wooden Package
Specification
5080x1250x1950
Trademark
LK
Origin
China
HS Code
8477101010
Production Capacity
500/Mon

Product Description

Brief introduction
LK group specializes in the design manufacture and sales of die casting machines, high precision injection molding machines, CNC machine centers, and industrial integrated control systems. Our market share of die casting machines is over 60%, the injection molding machine ranks among the top 3 in China.
We have over 10 production bases worldwide,1 in Taiwan, and 1 acquired company in Italy. Our injection molding machine centers are Zhongshan in Guangdong and Ningbo in Zhejiang.
There are over 60 sales and service centers in the world, and our high-quality after-sales service and 24-hour prompt response system provide customs all-around fully coverage customer service. K6 series adopts the new Internet of Things injection molding 5G concept, with independent knowledge and technology connotation. The injection power of this series is increased by 10% ~ 30%, the new machine hinge point optimization design, with low noise, energy-saving, environmental protection, cloud injection interface, and other significant characteristics.
Advantages
1. Enlarged design of the mode-locking structure
2. The whole machine layout is reasonable, the shape line is firm
3. The momentum is strong and the cycle is shorter
4. High response, low noise hydraulic system
5. High precision linear guide injection unit
6. Add cloud injection molding network interface
Use of application
Technical Parameter List
ITEM UNIT PT160
Shooting Part Shot Weight(PS) g 229 289 356
Screw Diameter mm 40 45 50
Injection Volume cm3 251 318 393
Injection Pressure MPa 228 180 146
Screw L/D Ratio L/D 25 22 20
Injection Rate cm3/s 153 194 239
Plasticizing Capacity Kg/hr 64 77 109
Screw Speed r/min 0-220
Hopper Capacity L 50
Clamping Part Locking Force kN 1600
Die Height (Min.-Max.) mm 180-520
Opening Stroke mm 430
Space Between Tie Bars mm 470×470
Ejector Stroke mm 140
Ejector Force kN 49
Others Motor Capacity kW 20.5
Max Working Pressure MPa 17.5
Oil Tank Capacity L 240
Heating Capacity kW 11.9
Machine Dimensions (L×W×H) mm 5080×1250×1950
