US$13,000.00-16,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Color & Page
Multi-Colour Printing Press
Usage
Label Printer, Cloths Printer
Automatic Grade
Automatic
System Supported
Windowsxp64
Print Head
I3200 Print Head/ 4 Printhead
Number of Spray Holes
3200 PCS
Max Speed
6pass, A4 Size:80PCS/H A3 Size: 55PCS/H
Sprinkler Maintenance
Self-Cleaning, Self-Moisturzing, Anti-Collision Sy
Printing Media
Cotton,Denim,Silk.Canvas,Knitting.and Other
Application Scope
Polo Shirts,Class Clothes,Group Clothes,Couples Cl
Ink Color
8+1 Color Cmyk Rgbo+W
Ink Supply System
Ink Supply System
Printable Format
380*480mm/480*580mm/900*480mm
Work Environment
Temperature:20-28ºC, Humidity:35%65%
Anti-Collision Plate
Prevent The Nozzle From Being Hit
Print Method
White and Color Simultaneous Printing
Specification
L*W*H: 2100*1280*1400(mm)
Packaging & Delivery
Package Size
227.00cm * 145.00cm * 166.00cm
Package Gross Weight
210.000kg
Product Description
Product Description
Company Profile
Nozzle blocking prevention
1,the cloth is paved, the height of the nozzle is confirmed, do not scrape the cloth! Otherwise, the nozzle is easily damaged
2, finish the goods every day, make sure that the test strip is no problem and then shut down, the test strip is sent to the corresponding after-sales group, and be sure to clean out the day of blockage! White ink ink pad daily moisturizer, do not allow water and alcohol
3, when the machine does not do goods for more than 24 hours, the machine needs to be started for 30 minutes, and the test bar to confirm the status of the nozzle
4. If the machine does not do goods for a long time, please operate according to the nozzle maintenance standard. If in doubt, contact the corresponding after-sales service in time
5. Clean the ink pad and scraper every day to avoid clumping and damaging the nozzle
6, ink bag, filter must be replaced once every three months, ink pot cleaning once every three months
7, indoor temperature: 15ºC ~ 28ºC, humidity: 65%, otherwise easy to block the nozzle
8, white ink ink do not replace at will, otherwise affect the fastness and blocking nozzle, can not be after-sales.
After-Sales Service
1. If you use our ink, we will always provide you with free repair service.
2. Technologists can speak fluent english and provide instant online support service.
3. Free technical training will be provide in the factory.
4. We will send you spare parts and inks in lower price.
5. We can issue you excludsive dealership after we confirm our cooperation and we will 100% loyal to our dealers.
Machine Maintenance Instructions
1. As for the ink cap, scraper and lifting plate clean, must be kept clean all the time.
2. Need to put some lunricating oil on the trolley track for every half a month or for every month.
3. Grating need be wiped with dry clean fabric for every month.
4. Need to put some water into the ink stack cap while the machie is printin. It greatly keeps the ink cap wet to prevent agglomeration and the print head blocked.
5. It is best to turn on the machine in two or three days if you do not use the machine for long time. And print the test strip or print some tasks to prevent the print head blocked.
6.The machine need to be kept cleaned all the time. If can kept like a new machine, which will better.
FAQ
Are you the manufacturer?
A:Sure.You can have a videos call with us, we show you our factory in production. We also welcome you to visit our factory.
What materials can i print?
It can print on cotton materials and 65% cotton mixed materials.
How long it takes to print one tshirt?
A: About 1.5-3 minutes base on different picture design and color of tshirt.
Do you support samples?
A: Sure, according to you picture, we will send out the sample within 24 hours.
Does the printhead be clogged easily?
A: no,as our printer is designed with powerful white ink circulation system to protect our printheads from being clogged easily.
How to maintain this printer?
A: Our printers need no special maintenance. You only need to remember on thing: after you finish your day's work,before the computer is turned off, you clean and test the nozzle of the machine,and then clean and test the nozzle again the next day when the machine is in use. Keep it moist to prevent the nozzle from clogging.
What's the machine installation?
A: We provide the machine usage&installation videos and instruction manual,afford the 24 hour online service support for oversea customers. If need, we could provide the on-site installation and training service.
How about the machine's package and transportation?
A: Each machine before leave the factory will be protected by film,be fastened on the bottom of the wooden case with iron nails, after the machine be packed, we will choose the transportation way and export service according customer's requirement installation and training service.
>>
