China Normal Precision Sumore Wooden Box 50mm Tools Milling Machine

Product Description

Product Description
China metal manual bridgeport universal gear drilling milling machine SP2233/SP2234 50mm horizontal vertical universal milling machine SP2233 SP2234 fresadora universal cutter mini horizontal vertical milling machine for hobby mini manual vertical milling and drilling machine price sp2208-II/SP2208-III/SP2208-IV SUMORE small milling drilling machine cheap mini torno fresadora Universal Vertical Drilling and milling machine for metal Hobby desktop mini desktop mill drill milling machine Mini metal milling machine made in China, but same quality with Japanese made milling machine SP2226 Bench Type mini universal Milling Machine is one of our most economic and durable mini universal Milling Machine. It sells very well; it is new condition not used universal Milling Machine. And it is small in size and delicate in design. This milling machine is made in China, but with same quality of Japan milling machine. The main features are as below:
Quick detais
1.Drilling capacity:50mm
2.Horizontal milling dia.:100mm
3.Vertical milling dia.:32 mm
4.Head tilt left & right:+45°
4.Spindle taper:R8 or MT4
5.Spindle speed: 270-2500rpm
7.Working tabel:260*1000mm
7.Power:1500W
Features/Advantages
1.Three axis hardened treatment, high rigidity.2.vertical horizontal multi-functional ,drilling ,milling, boring operation.3.X axis mechanical feed,Y.Z axis can be added the device4.Gear transmission milling head, stable transmission, compact structure ,easy maintenance, easy to operate
5.Uses standardized assemblies from the VH milling machine universal use as milling machines and drill press6.Easily shiftable gear drive ensures power transmission without losses7.With V-belt spindle drive and gear spindle drive8.Head swivels into the horizontal level on both sided via crank and toothed gear, easy activation of manual micro-feed for the spindle quill
Product Parameters

Model SP2233 SP2234 Max. drilling dia. 50mm Max. vertical milling dia. 32mm Max. horizontal milling dia. 100mm Max. boring dia. 100mm Table size 260*1000mm Table travel 450*280*380mm Spindle travel 125mm Taper of spindle MT4,R8 Range of spindle speed 270-2400r/min Power of motor 1.5KW Packing size 1250*1100*2000mm N.W. / G.W. 700/760K

Company Profile
As the professional and experienced manufacturer of lathe, mill , drill , cnc and other tools ,Shanghai SUMORE Industrial Group has been in this filed for more than 20 years.
We have got the certificates of CE, GS ,Rohs , UL ,etc . Also we have been in business with GSK ,Siemens ,Faunc and other famous companies within 50 countries all over the world.
Whether you need the standard or the customerised products , please contact us directly . Our professional and experienced engineers and after sale service team will meet your needs.
Hope to cooperate with you!

---
