B320X86X53 Rubber Track Rubber Crawler for Cat259b3

Product Description

B320X86X53 Rubber track rubber crawler for cat259B3
1.Product Information

1.Name of commodity	Rubber Track 320*86*53 for Yanmar B50 Machines
2.Width	320mm
3.Pitch	86mm
4.Links	53
5.Total Length	4558mm
6.Weight	158.00kg
7.Material	Rubber & Steel
8.Steel cord type	Continuous inner steel cord with joint free
9.Warranty	Guarantee one year under normal use

2.Application
Rubber track with size 320mm wide, 86mm pitch and 49 links, can be applied on the construction machinery as follow:
3.Special Features of the POOYERT Rubber Tracks
- 3 Metal Cores Wound Up: Higher durability & Better flexibility
- Smaller Contact Surface (Smaller Lug): Better grip & traction
- Bi Directional: Tracks are Interchangeable
- Reinforced Edges Between Lugs: Decreasing the chance of slicing
- Jointless: Track is much stronger than the joint type
4.Parameters
Please noted that, the parameter just show the part of our size range, if you cannot find your size, please kindly inform us by email or other ways, we will customize for you.

Skid Steer Loader
Width*Pitch length(mm)	Link	A	B	C	D	F	PATTERN	GUIDING
B182*72A	31-43	23	63	29	22	10	AE	A2
B250*72A	34-60	23	63	29	22	10	AE	A2
B250*72CT	34-60	29	76	38	30	21		A2
E250*72	34-60	29	76	36	27	22.5	CH	A2
B300*84	48-52	48	95	48	36	25	AE	A2
T300*86K	48-52	36	84	43.5	31.5	22	AA	A2
B320*84	50-53	46	96	48	34	25	AE	A2
T320*86K	48-52	36	84	43.5	31.5	25	CH	A2
B320*86	49-52	48	95	48	36	25	AE	A2
B400*86	52-55	48	97	48	36	25	AE	A2
T400*86K		38	84	44	32.5	29	AE	A2
B450*84	53-56	48	97	48	36	25	AE	A2
B450*86	52-55	48	97	48	36	25	AE	A2
T450*100K	48-65	50	104	47	44	30	CH	A2

DUMPER TRACK
Size width*pitch	link	A	B	C	D	F	pattern	guiding
320*90	52-56	32	86	50	35	28	AA	A2
U320*90	56-76	37	85	47	32	29	AA	A2
320*100	38-54	29	74	30	25	23	BN	A2
320*100W	37-65	38	80	34	25	22	CD	A2
350*100	49-60	45	112	45	48	27	AA	A2
U380*90	56-76	34	85	48	34	30	AA	A2
420*100	50-58	49	99	50.5	36	25	AA	A2
450*110	74	45	120	64	55	21	AL	A2
500*90	76-82	42	94	51	36	30	AA	A2
500*100	71	45	112	57	54	45	AL	A2
600*100	76-80	44	113	60	49	36	AL	A2
600*125	56-64	43	124	76	61	30	AL	A2
650*110	88	48	114	76	60	34	AL	A2
650*120	78	44	130	91	69	38	AL	A2
700*100	80-98	48	125	75	58	50	AL	A2
700*125	56-64	55	144	68	56	32	AL	A2
750*150	66	62	176	94	68	38	AL	A2
800*125	80	62	175	95	88	32	AL	A2
M800*150	66-68	60	148	73	71	35	AL	A2
K800*150	67-70	80	189	108	78	35	AL	A2
900*150	68-80	80	200	101	66	48	AL	A2
1000*150	86	78	210	101	58	37	AL	A2

Excavator Rubber Track
Width*Pitch length(mm)	Number of Links	Width*Pitch length(mm)	Number of Links	Width*Pitch length(mm)
130*72	28-53	300*52.5K	72-84	400*72.5KW
150*60	28-49	300*52.5KW	72-92	400*74
150*72	29-40	KB300*52.5	72-92	400*75.5K
170*60	30-40	KB300*52.5N	72-98	B400*86
180*60	30-40	JD300*52.5N	72-98	400*90
180*72	30-58	300*53K	80-84	Y400*142
180*72K	30-37	300*55	70-86	400*144
B180*72K	34-51	300*55.5K	76-82	Y400*144K
B180*72A	30-51	300*71K	72-55	420*100
H180*72	30-50	300*109N	25-42	450*71
190*60	30-40	K300*109	37-41	DW450*71
190*72	34-39	300*109WK	35-42	450*73.5
200*72	34-47	B300*84	78-52	450*76
200-*72K	37-47	T300*86K	48-52	450*81N
230*48	60-84	320*52.5	72-98	450*81W
230*48K	60-84	B320*52.5	68-98	KB450*81.5
230*72	42-56	320*54	70-84	K450*83.5
230*72K	42-56	B320*86	49-52	B450*84
230*96	30-48	320*90	52-56	B450*86
230*101	30-36	320*100	38-54	450*90
250*47K	84	320*100W	37-65	KU450*90
250*48.5K	80-88	Y320*106K	39-43	T450*100K
250*52.5K	72-78	350*52.5	70-92	K450*163
250*72	47-57	350*54.5K	80-86	485*92W
B250*72	34-60	B350*55K	77-98	500*90
B250*72B	42-58	350*56	80-86	500-92
E250*72	37-58	350*75.5K	74	500*92W
250*96	35-38	350*90	42-56	500*100
250*109	35-38	350*100	46-60	K500*146
260*55.5K	74-80	350*108	40-46	600*100
Y260*96	38-41	350*109	41-44	600*125
260*109	35-39	Y370*107K	39-41	700*100
280*72	45-64	400*72.5N	70-80	750*150
Y280*106K	35-42	400*72.5W	68-92	800*125
300*52.5N	72-98	Y400*72.5K	72-74
300*52.5W	72-92	KB400*72.5K	68-76

---
