| US$1.00-10,000.00 | 1 Piece (MOQ) |
| Technical Parameters | Unit | MY1224 | MYS1224 | |
| Max. workpiece to be Ground ( L× W× H) | mm | 630× 310× 390 | 630× 310× 390 | |
| Max. Grinding Length | mm | 630 | 630 | |
| Max. Grinding Width | mm | 320 | 320 | |
| Distance From Table Surface To Spindle Center | mm | 550 | 550 | |
| Slide way | V-type rail with Steel-ball | V-type rail with Steel-ball | ||
| V-type rail with Steel-ball | Kg | 200 | 200 | |
| Table Size (L× W) | mm | 600× 300 | 600× 300 | |
| Number of T -Slot | mm× n | 14× 1 | 14× 1 | |
| V-type rail with Steel-ball (Grinding Length/Width) | m/min | 3-20 | 3-20 | |
| Cross Feed On Handwheel | mm | 0.02/Graduation2.5/revolution | 0.02/Graduation2.5/revolution | |
| Vertical Feed On Handwheel | mm | 0.01/Graduation1.25/revolution | 0.01/Graduation1.25/revolution | |
| Wheel Size (dia× width× bore ) | mm | 200× 20× 31.75 | 200× 20× 31.75 | |
| Spindle Speeds | 50Hz | rpm | 2850 | 2850 |
| 0-6000 | 30-6000 | |||
| Totale Power | Kw | 3.79 | 2.5 | |
| Spindle Motor | Kw | 2.2 | 2.2 | |
| Working Pressure | Mpa | 3 | 3 | |
| Max. Capacity | L/min | 20 | 20 | |
| Minimum Of Numerical | L | 80 | 80 | |
| Surface Roughness | μ m | Ra0.63 | Ra0.63 | |
| Paraller Level | mm | 300.0.005 | 300.0.005 | |
| Machine Size (L× W× H) | mm | 1900× 1530× 1830 | 1900× 1530× 1830 | |
| Packing Size (L× W× H) | mm | 1980× 1530× 2030 | 1980× 1530× 2030 | |
| Gross/Net | T | 1.2/1.33 | 1.1/1.2 | |
