| Maximum drilling diameter | 35mm |
| Tapping the largest capacity (steel/casting) | M14/M18 |
| Workbench stroke | 510mm |
| Column diameter | 120mm |
| Spindle stroke | 150mm |
| Spindle taper | MT4 |
| Spindle speed | 75-3010rpm |
| Workbench size | 500×400mm |
| Base working surface size | 670×400mm |
| Spindle axis to column surface | 320mm |
| Maximum distance from spindle end to base | 960-1215mm |
| Maximum distance from spindle end to worktable | 880mm |
| The worktable rotates with the column | 0°-360° |
| Motor | 1.5/18.kg-380v |
| N.W./G.W. | 307/368kg |
| Machine size | 560mm×680×1850mm |
| Package Size | 1700×670×850mm |
