| Max. swing over bed | 210mm |
| Max. swing over tool post | 125mm |
| Max.machining length | 400mm |
| Spindle speed range | 50-2500rpm |
| Spindle taper | MT3 |
| Spindle bore | 21mm |
| Small carriage travel | 55mm |
| Middle carriage travel | 75mm |
| Taper of tail-stock | MT2 |
| Max. travel of tail-stock sleeve | 65mm |
| Longitudinal feed | 0.1/0.2mm/U |
| Processing metric thread range | 0.25-3.0mm |
| Processing inch thread range | 8-44t.p.i |
| Motor power | 220V 600W 50HZ |
| Dimensions (L*W*H) | 930*430*360mm |
| Packing Size | 900*470*500mm |
| Net weight / Gross weight | 65/85KG |
