| Model | FXC-05 | FXC-10 | FXC-12 | FXC-20 | FXC-30 |
| Camera/lens Specifications | |||||
| Image Sensor | 1/2 8 inch CMOS sensor | ||||
| Effective pixels | 2.07 MP (mega pixels) 16:9 | ||||
| Video signal | HDMI, SDI, HD Base T Interface video format 1080P60/50/30/25/59 . 94/29 . 97; 1080I60/50/59 . 94 ; 720P60/50/30/25/59 . 94/29 . 97 | ||||
| USB3 . 0 interface video format: 1) USB3.0: 1920x1080P60/50/30/25; 1280x720P60/50/30/25; 960x540P30; 640x360P30; 640x480P30; 352x288 P30;800x600 P30 2) USB3 . 0 compatible with USB2 . 0 video format: 960x540P30 ; 640x360P30; 1280x720P10/15; 720x576P50; 720x480P60; 640x480P30; 352x288P30; 800x600P30 | |||||
| USB2 . 0 interface video format: 176x144/320x240/320x180/352x288/640x480/720x480/720x576/640x360/800x600/960x540/ 1024x576/1024x768/1280x720/1920x1080P30/25/20/15/10/5 | |||||
| Lens optical zoom | 5 x optical zoom f=3 . 1-15 . 5mm | 10 x optical zoom f=4 . 7-47mm | 12 x optical zoom f=3 . 9-46 . 8mm | 20 x optical zoom f=5 . 5-110mm | 30 x optical zoom f=4.3-129mm |
| Angle of View | 20° - 83 . 7° | 6 .43° - 60 . 9° | 6 . 3° - 72 . 5° | 3.3° - 54. 7° | 2.34° - 65.1° |
| Aperture F-stop value: | F1 . 8 - F2 . 8 | F1 . 6 - F3 . 0 | F1 . 8 - F2 .4 | F1 . 6 - F3 . 5 | F1 . 6 - F4 . 7 |
| Digital zoom | 10 x | ||||
| Minimum illumination (Lux) | 0.5 Lux（F1 . 8, AGC ON） | ||||
| Digital noise reduction (DNR) | 2D & 3D digital noise reduction | ||||
| White balance | Automatic/manual/one-click white balance /3000K/3500K/4000K/4500K/5000K/5500K/6000K/6500K/7000K | ||||
| Focus | Auto/ manual/ one-click focus | ||||
| Aperture | Auto/ manual | ||||
| Electronic Shutter | Auto/ manual | ||||
| Backlight compensation | ON/OFF | ||||
| Dynamic Range (DNR) | Off/dynamic level adjustment | ||||
| Video Adjustment | Brightness, chroma, saturation, contrast, sharpness, black and white mode, gamma curve | ||||
| Signal to Noise Ratio (SNR) | >55dB | ||||
| Interface details | |||||
| Interface model and details | SH : SDI, HDMI, LAN , RS232(LOOP out), RS485,A-IN, NDI (optional) U2 : USB2 . 0 , LAN, RS232 (LOOP out),A-IN U3 : USB3 . 0 , LAN, RS232 (LOOP out),A-IN HD : HDBaseT(POE ), LAN , A-IN, RS232 (input) HM : HDMI, LAN , RS232 (input) U2U3 : USB2 . 0 , USB3 . 0, HDMI, LAN , RS232 (input) | ||||
| FXC-20-SH | 20X zoom, SDI, HDMI, LAN , RS232 (LOOP out), RS485, A-IN, NDI (optional) |
