Series Copper Lug and Terminals

Product Description

250 nylon male/female terminals
1, cable lugs are suitable for the connection of copper conductors in power cable with electronic equipment
2, Material: They are made of higher 99.99 % pure copper tube T2.
3, Working temperature -55oC-150oC
4, Surface: Tin-plated
5, Insulated material: PVC, nylon
Product Description
The company has more than 95% of the full automatic production lines, nissan 200 tons, production capacity continues to adjust and expand, to meet the challenge of the market at any time.
Through the European CE safety certification, American UL safety certification, the company has a SC Japan JIS standard, the German DIN standards, AWG American standards, etc.
Companies always adhere to: quality first, service first, from raw materials into the factory inspection, process inspection to every working procedure, outbound packaging cengcengbaguan .Company has own copper pipe, copper strip, copper platoon of raw material processing factory, with strong competitive advantage price on equal quality to every guest get the maximum benefits.

ITEM NO	DIMENSION mm						(A.W.G.)mm2
	φE	φD	φd	W	B	L	WIRE ANGE
GC1.5-3	3.2	3.7	1.8	8	6	16	22-16 A.W.G. 0.5-1.5 mm2
GC1.5-4	4.3					17
GC1.5-5	5.3			10	7	19
GC1.5-6	6.5					20
GC2.5-3	3.2	3.9	2.3	8	7	17	16-14 A.W.G. 1.5-2.5 mm2
GC2.5-4	4.3					18
GC2.5-5	5.3			10		20
GC2.5-6	6.5
GC2.5-8	8.3	4.3		12.5		22.5
GC4-4	4.3	4.7	3	10	8	21	14-12 A.W.G . 2.5-4 mm2
GC4-5	5.3					22
GC4-6	6.5					23
GC4-8	8.3			12.5		24
GC6-4	4.3	5.9	4	10	9.5	24.6	12-10 A.W.G. 4-6 mm2
GC6-5	5.3
GC6-6	6.5			11
GC6-8	8.3			12.5		27.3
GC6-10	10.3	6.2		15		28.3
GC10-4	4.3	6.6	4.5	11	13	30	8 A.W.G. 10 mm2
GC10-5	5.3
GC10-6	6.5
GC10-8	8.3			12.5
GC10-10	10.3	6.9		16		34.1
GC10-12	12.7			18	12
GC16-5	5.3	7.5	5.5	11	14	30.7	6 A.W.G . 16 mm2
GC16-6	6.5
GC16-8	8.3			12.5	13
GC16-10	10.3			16	14	35.9
GC16-12	12.7	8.1		18	13
GC16-14	14.8			20		37.9
GC25-5	5.3	9.1	6.7	13	13	32.2	4 A.W.G. 25 mm2
GC25-6	6.5
GC25-8	8.3
GC25-10	10.3			16	14	36.9
GC25-12	12.7			18	13
GC25-14	14.8			20		38.9
GC35-5	5.3	11	8.6	16	16	37.6	2 A.W.G. 35 mm2
GC35-6	6.5
GC35-8	8.3
GC35-10	10.3			17		41.5
GC35-12	12.7			18
GC35-14	14.8			20		43.5
GC35-16	16.5			23		45.5
GC50-5	5.3	12.4	9.5	18	17	41	1/0 A.W.G. 50 mm2
GC50-6	6.5
GC50-8	8.3
GC50-10	10.3					44
GC50-12	12.7			19
GC50-14	14.8			21	19	52.8
GC50-16	16.5			23
GC70-5	5.3	15	12	22	21.5	52.4	2/0 A.W.G. 70 mm2
GC70-6	6.5
GC70-8	8.3
GC70-10	10.3
GC70-12	12.7
GC70-14	14.8					55
GC70-16	16.5			24	20
GC70-20	20.9			30		60

---
