Wallys Communications (Suzhou ) Co., LTD
With over 15 years of experience in wireless industry and penetrating market olfaction, Wallys has designed and manufactured many high quality and cost-effective routerboards and wireless network cards
products:
wifi6 router
WiFi 6 (802.11ax)
802.11ac，wireless
WEB:/
EMAIL:sales@wallystech.com
DR9074-5G(PN02.1) QCN9074 802.11ax 4x4 MU-MIMO 5GHz wifi6 11ax 4x4 5G M.2
Features
■ Qualcomm Atheros QCN9074
■ 5GHz, max 23dBm per chain, up to 4949Mbps
■ Single Band 5GHz 4x4 WiFi 6 (802.11ax)
■ 4 spatial streams (4SS)
■ M.2 E Key Interface
■ PCI Express 3.0 Interface
■ Supports Dynamic Frequency Selection (DFS)
Parameter
| Rating
| Unit
|
Operating Temperature Range
| -20 to 70
| ºC
|
Storage Temperature Range
| -40 to 90
| ºC
|
Operating Humidity Range
| 5 to +95 (non-condensing)
| %
|
Storage Humidity Range
| 0 to +90 (non-condensing)
| %
|
Symbol
| Parameter
|
Chipset
| Qualcomm Atheros QCN9074
|
WLAN Host Interface
| PCI Express 3.0 Interface
|
System Memory
| 2Mbit serial I²C bus EEPROM
|
Standard Operating Voltage
| 5V
|
Operating Systems
| QSDK
|
Host Interface
| M.2 E Key
|
Antenna Cable / Port
| 4 x MMCX Connectors,4T4R
|
Frequency Range
| 5.15GHz-5.95GHz
|
Data Rates for WALN
| 5GHz, max 23dBm per chain, up to 4949Mbps
|
Channel Spectrum Widths for WLAN
| Support 20/40/80/160MHz at 5GHz
|
Modulation Techniques
| OFDMA: BPSK, QPSK, DBPSK, DQPSK,16-QAM, 64-QAM, 256-QAM,1024-QAM, 4096-QAM
|
Temperature Range
| Operating: -20°C to 70°C, Storage: -40°C to 90°C
|
Humidity
| Operating: 5% to 95% (non-condensing), Storage: Max. 90% (non-condensing)
|
Certification
| TBD
|
Power Consumption
| TBD
|
Reference Design
| PN02.1
|
Dimensions (WxHxD)
| 57mm x 63mm x 6mm
|
| Pin No. | Name | Pin No. | Name |
| 1 | GND
| 2 | VDD3P3_PCIE
|
| 3 |
| 4 | VDD3P3_PCIE
|
| 5 |
| 6 | PCIE_LED0
|
| 7 | GND
| 8 | GPIO46_WCI2_UART_TXD_PCIE
|
| 9 | TP19
| 10 | GPIO47_WCI2_UART_RXD_PCIE
|
| 11 |
| 12 |
|
| 13 |
| 14 |
|
| 15 | VDD_XPA_PCIE
| 16 | PCIE_LED1
|
| 17 | VDD_XPA_PCIE
| 18 | GND
|
| 19 | VDD_XPA_PCIE
| 20 |
|
| 21 | VDD_XPA_PCIE
| 22 |
|
| 23 | VDD_XPA_PCIE
|
|
|
|
|
|
|
| 33 | GND
| 32 |
|
| 35 | PCIE0_RX0_P
| 34 |
|
| 37 | PCIE0_RX0_N
| 36 |
|
| 39 | GND
| 38 | MOD_BT_STS_2
|
| 41 | PCIE0_TX0_P
| 40 | MOD_WL_ACT_2
|
| 43 | PCIE0_TX0_N
| 42 | PINE_BT_ACT_2
|
| 45 | GND
| 44 | MOD_BT_STS
|
| 47 | PCIE0_REFCLK_P
| 46 | MOD_WL_ACT
|
| 49 | PCIE0_REFCLK_N
| 48 | PINE_BT_ACT
|
| 51 | GND
| 50 |
|
| 53 | PCIE0_CLKREQ_3P3_N
| 52 | PCIE0_PERST_3P3
|
| 55 | PCIE0_WAKE_3P3_N
| 54 |
|
| 57 | GND
| 56 |
|
| 59 | PCIE0_RX1_P
| 58 |
|
| 61 | PCIE0_RX1_N
| 60 |
|
| 63 | GND
| 62 |
|
| 65 | PCIE0_TX1_P
| 64 |
|
| 67 | PCIE0_TX1_N
| 66 |
|
| 69 | GND
| 68 |
|
| 71 |
| 70 |
|
| 73 |
| 72 | VDD3P3_PCIE
|
| 75 | GND
| 74 | VDD3P3_PCIE
|
>>
