New Horizontal Directional Drilling Rig HDD for Sale Xz1000A

Product Description

Horizontal Directional Drilling Rig HDD for Sale Xz1000A
Product Description 1.Hydraulic pilot control, provide comfortable operating performance and flexible regulation, first-class brand of hydraulic components to ensure the reliability of the machine hydraulic system.
2.Carriage and clamp use double floating patented technology can greatly protect the drill pipe thread, increase the service life of the drill pipe.
3.High-speed sliding systems, Piston Motor to achieve high and low sliding speed of carriage, increasing the ability to adapt the machine working conditions, promote construction efficiency.
4.Stable chassis support, using the classical H type beam structure, quality rubber track, frog Outrigger, provides a strong guarantee for the stability of construction.
Technical Parameters

Track length	3930mm
Track outside width	2900mm
Track width	500mm
Wheel base	3165mm
The number of roller	7 units * 2
Walking reducer	TM30VD * 2
Driving force	170 kN
Gradability	30%
Walking speed	2.5 km/h
The total weight	23T

2. The engine system
Choosing Cummins turbo engine. It is powerful. Meeting the China's second stage emission standards.

Engine type	6LTAA8.9-C360
Rated power	264kW
Max. torque	1400 N•m /(1400r/min)
Rated speed	2200 r/min
Standard	Second stage
Main engine fuel tank volume	425L

3. The hydraulic system
Using the load sensitive control and electro-hydraulic proportional control and several advanced control technology. The imported components are reliable in quality.

Power head rotation system
Rotation pump	Rexroth A11VO145
Pressure	320bar
Push and pull valve	AMCA APV-22
Motor	Rexroth A6VM107×2
Power head push and pull system
Push and pull pump	Rexroth A11VO145
Pressure	320bar
Motor	Rexroth A6VM107×4
Push and pull valve	AMCA APV-22
The hydraulic oil tank volume	750L

Product Pictures
