Cbb61 Electronic Component High Quality RoHS 1UF 350VAC Bm Fan Motor Run Capacitor

US$1.00
300-999 Pieces
US$0.50
1,000-4,999 Pieces
US$0.20
5,000+ Pieces

Basic Info.

Packaging Type
Through Hole
Capacitance
0.5-30UF
Structure
Variable Capacitor
Manufacturing Material
Polypropylene
Electrolyte
Electric Heating
Usage
High Frequency Coupling
Name
Black Capacitor
Model
Cbb61 Capacitor
Matierla
Plastic Body
Appearance
Square and Black
Terminals
Pin and Wire
Transport Package
Package
Specification
37*14*28
Trademark
DOMICOOL
Origin
China
HS Code
853225900
Production Capacity
1200000pieces / Day

Product Description

1.Specifications
CBB61 Series Construction Dielectric: polypropylene film Plastic & Box can Dry type Features Self-heating properties Low dissipation factor P0 safety class to IEC 60252-1 High insulation resistance Typical applications For general sine wave applications, mainly as motor run capacitor Terminals Fast on Tinned Copper Wire
Technical data and specifications
Reference standards IEC 60252-1
Safety class according IEC 60252-1 P0
Life expectancy to IEC 60252-1 3,000 h( C)~10,000 h(B)
Rated capacitance CR 0.5 µF~30 µF
Tolerance ±5%
Rated voltage VR 110VAC~500VAC
Rated frequency FR 50/60Hz
Maximum ratings
Maximum permissible votage Vmax 1.1*VR (VR=Rated voltage)
Maximum permissible current Imax 1.3*IR (IR=Rated current)
Test data
AC test voltage terminal to terminal VTT 2*VR, 2s (routine test)
2*VR, 60s (type test)
Dissipation factor tan δ ≤0.002 (50Hz)
Climatic data
Climatic category 25/085/21 to IEC 60068-1
Lower category Tmin -25ºC
Upper category Tmax +85ºC
Damp heat test Ttest 21 days
Dimensions (mm)
Capacitance (uF/MFD) 250-300Vac 450-500Vac
L W H L W H
0.5 37 13 23 37 13 23
1 37 13 23 37 13 23
1.5 37 13 23 37 13 23
2 37 13 23 37 13 23
2.5 37 13 23 47 18 29
3 47 18 29 47 18 29
3.5 47 18 29 47 18 29
4 47 18 29 47 18 34
5 47 18 29 47 22 34
6 47 18 34 47 22 34
8 47 22 34 48 26 38
10 47 22 34 58 26 44
12 48 26 38 58 26 44
12.5 48 26 38 58 26 44
14 48 26 38 58 26 44
15 48 26 38 58 26 44
16 48 26 38 58 26 44
18 58 26 44 58 26 44
20 58 26 44 55 32 49
22 58 26 44 55 32 49
24 55 32 49 55 32 49
25 55 32 49 55 32 49
28 55 32 49 55 32 49
30 55 32 49 55 32 49
Note: Can be manufactured according to customer's request.
2. DESCRIPETION
3.FACTORY WORKSHOP
