US$11,580.00-20,298.00
|
1 Piece
(MOQ)
|
Basic Info.
Function
Storage Pressure Vessel
Application
Liquefied Gas
Pressure
1.6MPa≤p<10.0MPa
Storage Medium
Flammable/Toxic
Pressure Level
Medium Pressure (1.6MPa≤p<10.0MPa)
Loading Capacity
50cbm, 50000liters, 25ton
Hydraulic Test Pressure
2.21MPa 22.1bar
Tank Diameter (mm)
DN2600, DN2700
Usage
LPG Gas Storage, Station Tank
Logo
as Customer′s Request
Transport Package
Naked, Waxed
Specification
13866 x 3132 x 3722 mm
Production Capacity
500 Unit/Month
Product Description
40000 Liters LPG Storage Tank 20mt LPG Gas Station Tank Filling Plant
Product Description
1. LPG Tank Storage Content: LPG Gas, Propane, Butane, Liquid Ammonia, etc
2. Tank Design Standard: GB150-2013, ASME Standard with U STAMP,
3. Test: 100% Radiaographic Test, Magnetic Power Test, Water Pressure.
40000 Liters LPG Storage Tank
| 40CBM LPG TANK DIMENSIONS |
| Volume of Tank | 40CBM |
| Filling Weight | 15960 kg |
| Tank Weight | 9380 kg |
| Thickness of Shell (mm) | 14 mm |
| Thickness of End plate (mm) | 12 mm |
| Tank Diameter (mm) | 2400 mm |
| External Dimensions (mm) (length x width x height) | 9270 x 2428 x 3018 mm |
| Material of Tank and Main Pressure Parts | Carbon Steel Q345R |
| Filling Medium | Liquefied Petroleum Gas ( Propane) |
| Design Pressure | 1.77 MPa / 17.7Bar |
| Corrosion Allowance | 1 mm |
| Medium Density | 420 kg/ cbm |
| Manufacturing Standard: Pressure vessels, Supervision Regulation on Safety Technology for Stationary Pressure Vessels of China. |
| Main parts of LPG Tank |
| Item | Specification | Quantity |
| Discharge Pipe | DN80 | 1 |
| Inflow Pipe | DN80 | 1 |
| Gas phase balance pipes | DN50 | 2 |
| Drain Hole | DN50 | 1 |
| Manhole | DN450 | 1 |
| Air-out Pipe | DN50 | 1 |
| Safety Valve Pipe | DN80 | 2 |
Safety Accessories (Included in the quotation):
Cut-off Valve, Needle Valve, Safety Valve, Magnetic Liquid level meter, Pressure gauge, Temperature Gauge.
|
Product Diagram
