FRP/GRP marine grade fibreglass panels / plastic walkway grating for platform

Product Description

Product Description
Product Description
FRP/GRP marine grade fibreglass panels / plastic walkway grating for platform
Glass fiber reinforced plastic (FRP) grid and glass fiber reinforced plastic plate, is a kind of glass fiber reinforced material,
unsaturated polyester resin as matrix, through special processing and become a kind of plate material, with lots of blank space FRP gratings can be used as structure materials, used as a corrosion environment of ship deck stair floor trench cover platform plank road with corrosion such as flame retardant non-magnetic insulated colorful sample a variety of alternative style form, etc
Moulde Grating structure :
1:Integral one-piece construction distributes the load to adjoining cross bars and bearing bars for  even load distribution.
2:Glass Roving winding in alternating layers within thermoset resins.
3:Slip-resistant top surface.
Product specifications
Material:Fiberglass + Resin base (ORTHO,ISO,VE)Color:Yellow, Orange, Blue, Green, Grey, etc. can be cutomized
Surface treatment: smooth ,gritted ,

Mesh size (mm)	Thickness (mm)	Panel size (mm)	Weight (kg/m3)	Open Area(%)
38*38	25mm	1220*3660; 1220*4040	12.3	68
19*19		1220*3660	1220*3660; 1220*4040	16.81	42
40*40		1220*36601000*4007	1000*4000	12	67
100*25		1220*3660	1220*3660	13	67
38*38	30mm	1220*3660;1000*4000	14.6	68
38*38	38mm	1220*3660	19.5	68
38*38/19*19		1010*4040	1220*3660	23.5	42
40*40	40mm	1007*3007;1220*3660	19.2	67
50*50	50mm	1220*3660;1000*4000	23.51	71
38*38	60mm	1220*3660; 1220*4040	50.43	58

Production Process
product displays
Process &Packing
