US$33,000.00-35,700.00
|
1 Piece
(MOQ)
|
Basic Info.
Emission Standard
Euro III
Dimension(mm)
5270*2450*3140
Min Ground Clearance(mm)
430
Wheel Base Front/Rear(mm)
1900/1830(Normal)
Transport Package
W/O Package
Trademark
World or as required
Production Capacity
10, 000 PCS/Year
Product Description
High Quality Agricultural Power Tiller Farm Walking Cutting Tractor
Features:
1.Bosch TDCI technology high quality 6 cylinders engine provides strong power and great performance at working.
2.Transmission 32F+32R shuttle shift with creeper of minimum speed around 6m/min allows machine perform well in low-speed working condition
3.Enhanced transmission, using helical gear and gear grinding process to achieve high transmission torque and strong bearing capacity
4.High quality bearing are used for long work prolonging work life
5.Equipped cabin as standard, air brake optional for road transport
| Model | WD2004G | WD2204G |
| Structure | 4*4 |
| Engine | Engine Power@speed(HP) | 200@2300 | 220@2300 |
| Engine Type | 6 Cylinder, Inline, Vertical, Water-cooled, diesel engine |
| Fuel Tank Capacity(L) | 410 |
| Battery | 12V |
| Air Cleaner | Dry |
| Transmission | Gears | Shuttle 32F + 32R with Creeper |
| Clutch | Dual Clutch, Independent |
| Brake | Mechanical disc |
| Differential Lock | Pin Type, Mechanical |
| PTO System | Direction of turning | Clockwise,viewed from tractor rear |
| Diameter of PTO Shaft(mm) | 48 |
| PTO Speeds(rpm) | 760/850 |
| Hydraulic system | 3 Point Hitch | Category 3 |
| Control System | Position ,draft |
| Rear Auxiliary Remote Valves | 4 groups |
| Lifting Capacity(KG) | >=5294 | >=5824 |
| Other Parameters | Steering | Hydraulic Power Steering |
| Dimension(mm)@Cabin | 5510*2665*3140 |
| Gorund Clearance(mm) | 470 |
| Tires(F/R) | 16.9-28/20.8-38 R-1, other size optional |
| Wheel Base (mm) | 2860 |
| Wheel Track (F/R)(mm) | | |
| Ballast Weight Front/Rear(kg) | 720/540 |
| Min Operation Weight(kg) | 7250(Cabin) |
>>
