Bakery Equipment Hamburger Maker Machine Line Hot Dog Bun and Toast Machine

Product Description

ADVANTAGES: -High Accuracy of Dough Ball Weight-Easy for Cleaning-Special Designed for Hamburger Bun, Hot Dog, etc.
Extruder Divider head:
The machine .suitable to work soft and semi-tough dough ,is equipped with stainless steelHopper for a capacity of 20kg each time. the dough handled thanks to the system which is compressed in the portion chambers and appropriately adjusted give the required weight .once the weight is fixed. Finally the pieces are deposited on the moulding belts

The machine is equipped with "Touch screen" control panel with Setting programs and PLC for the adjustment of weight ,production speed and rounding speed.Complete with electric and electronic connections for the make-up line
Hourly production :5000-30000 Pcs/h for 4 row-6row-8row
Machine complete with From 50 to 150gram according with the dividing set up

Round molding
The dough pieces are discharged and enters the rounding mould ,which is easily changeable according to the requested weight During the machine operation it is possible by potentiometer to make the contemporaneous and independent regulation of the rounding and production speed.

-Guillotine
The guillotine ensure very accurate dough weight. and Precise product drop position

Intermediate Proofer
For resting time according with customer require. the proofer is complete with exhaust
fan and is manufactured in heavy -duty painted thick steel structure for on heavy -duty use ,complete with
-By pass belt of the proofer on the reverse motion
-Discharge conveyor belt
1:Pressing roller
For the pressing roller ,it for produce hamburger.
2:Adjustable set of lateral side Guide
For the pressing board or the moving belt ,it's used to close the ends of the fingers rolls especially in order to produce hot-dog bun

Panning System
The line using special panning system ensures the accurate position of dough into the discharger through intelligent controller.
Arranging speed:12000-24000pcs/hour
Panning system can be working with automatic tray feeding line
And transfer fed tray to automatic proofer tower or working by
manual .

---
