Product Description
Product Description
TM600 ADSL2+ Tester All-in-one ADSL/ADSL2+/OPM/ VFL/TDR Function/Tone Tracker Product Description Specifications:- TM-600 VDSL tester specially designed for xDSL line test (xDSL include: ADSL, ADSL2, ADSL2+, READSL, VDSL2 etc) and maintenance It provides xDSL test, PPPoE dial test, DMM test, Modem emulation, line voltage indication and so on.- TM-600 VDSL Tester also introduces the Optical Power Meter and Visual Fault Locator function into the unit, as well as the TDR function;- It is one multifunction tester with smart size, true color LCD and powerful management software as well as the 6600mah rechargeable battery etcKey Features:Test objects: ADSL; ADSL2; ADSL2+; READSLFast Copper tests with DMM (ACV, DCV, Loop and Insulation Resistance, Capacitance, Distance)Supports Modem emulation and simulating login to InternetSupports ISP login (username / password) and IP Ping test (WAN PING Test, LAN PING Test)Supports all multi-protocol, PPPoE / PPPoA (LLC or VC-MUX)Connects to CO via alligator clip or RJ11Rechargeable Li-ion BatteryBeep and LEDs alarm indications (Lower Power, PPP, LAN,xDSL)Data memory fuctionLCD display, Menu operationAuto shut off if no any operation on keyboardCompliant with all known DSLAMsSoftware managementSimple, portable and money-savedFunctions:DSL Physical layer testModem Emulation (Replace the user Modem completely)PPPoE Dialing (RFC1683,RFC2684,RFC2516)PPPoA Dialing (RFC2364)Telephone FunctionDMM TestPing Function (WAN & LAN)Data upload to computer and software managementSetup system parameter: backlight time, shut off automatically time without operation, press tone,Revise PPPoE / PPPoA dial attribute, user name and password; restore factory value and so on.Check dangerous voltageOptical Power Meter (Optional)Visual Fault Locator (Optional)Tone Tracker (Optional)TDR Cable Fault Locator (Optional)ADSL2+:Standards: ITU G.992.1(G.dmt),ITU G.992.2(G.lite),ITU G.994.1(G.hs),ANSI T1.413 issue #2,ITU G.992.5(ADSL2+)Annex L,Up channel rate:0~1.2MbpsDown channel rate:0~24MbpsUp/Down attenuation:0~63.5dBUp/Down noise margin:0~32dBOutput power:AvailableError test CRC,FEC,HEC,NCD,LOSDisplay DSL connect mode:AvailableDisplay channel bit map:AvailableADSL:Standards ITU G.992.1 (G.dmt)ITU G.992.2(G.lite)ITU G.994.1(G.hs)ANSI T1.413 Issue # 2ITU G.992.5(ADSL2+)Annex LUp channel rate:0~1.2MbpsDown channel rate:0~24MbpsUp/Down attenuation:0~63.5dBUp/Down noise margin:0~32dBOutput power:AvailableError test:LOS,HEC,FEC,CRCDisplay DSL connect mode:AvailableDisplay channel bit map:AvailableDMM Test:DC voltage (V):0~400AC voltage (V):0~400Loop resistance(Ω):0~20000Capacitance (nF):0~1000Insulation resistance (MΩ):0~50General Specification:LCD:800X480TFTPower Supply:Internal Rechargeable 6600mAH Li-ion batteryBattery Duration:4 to 5 hoursWorking temperature:10-40°CWorking moisture:5%-90%Dimensions:170mm×70mm×52mmWeight:<0.6kgPackage List:- 1 x TM600 ADSL2+ Tester Detail photo FAQ Q1. Can I have a sample order?A: Yes, we welcome sample order to test and check quality. Q2. What about the lead time?A: Sample ususally take within 3 working days. Q3. Do you have any MOQ (minimum order quality)limit?A: For standard product, usually 1pcs/item. For the OEM order, MOQ at least 50pcs/item. Q4. How to proceed an order?A: After buyer confirm the product&price is ok and ready to buy, the order will be please tell us your delivery address, phone number, sometimes need email. Then we can draft the order and it will have an alibaba paying link. Q5. After paid, what info of the supplier provided?A: Tracking number. Q6: Do you offer a guarantee and after-service for the products?A: Yes, 6- 12 months warranty for our products. Note: We will do not take responsibility for Man-made damage or improper operation. Delivery damage will be negotiated. Packing and ShippingPackage: Normally we use the standard paper package to export worldwide. Shipping : 1. By Couriers: DHL, UPS, FEDEX, TNT are the main courier we are co-operating at present. 2. By chinese small parcel, usually for the customer to save the cost. But Chinese small parcel has the risk for lost parcel. Note: If we got the parcel back, we only can refund the item cost. If we didn't get the parcel,then sorry we can't refund any.3. By Air: Delivery from the Shenzhen airport to customers’ destination city airport.4. By Sea: Delivery from the Shenzhen seaport . Company Information Company informationTZT has been specializing in Business & Industry, Hobbies & Toys,CNC Products and Health care supplies for over 5 years. We committed to enhancing customer satisfaction by continually improving the process with a vision of expertise in the field. Aiming to provide high quality products and great service for buyer,we are strict on product quality control and offer instant communication service. Welcome to contact us!Our Advantages:- Source only the best consumer goods and ensure the highest quality.- Streamline the buying and payment process, and make it as easy as possible.- Help the customers all over the world discover products and manufacturers in China.- The Shortest order processed time and speed delivery
>>
