1200mm PP Double Layer Film Blowing Machine

Product Description

The machine produces excellent plastic of film uniform thickness, transparency, smoothness, shrinkage and other quality indicatores of the printing grade films technical standards, as it uses many technologies such as rotary winder, frequency control and automatic temperatrue control.
Widely used in daily use package and industrial package such as food stuff, textile, garment and daliy products etc..

Model	FMP-500	FMP-700	FMP-800	FMP-1000	FMP-1200
suitable material	PP / PPE
thickness	0.02--0.20mm
film width(mm)	60--400	100--650	150--700	250--900	300--1000
max output	40kgs/hr	55kgs/hr	70kgs/hr	90kgs/hr	120kgs/hr

Extruder

screw diameter	Φ45mm	Φ55mm	Φ65mm	Φ75mm	Φ85mm
L/D ratio	30:1
temp. controller	4 zone	4 zone	5 zone	5 zone	6 zone
barrel cooling	120w*2	120w*2	120w*2	250w*3	250w*3
driving motor	11kw	15kw	18.5kw	30kw	45kw

Die head

die diameter	Φ130mm	Φ180mm	Φ250mm	Φ320mm	Φ400mm
air ring diameter	Φ250mm	Φ300mm	Φ350mm	Φ450mm	Φ550mm
die structure	Spiral mandrel die chrome plated surface 40Cr
cooling fan	550w	950w	1.1kw	1.5kw	2.2kw

Take up unit part

take up width	500mm	700mm	800mm	1000mm	1200mm
effective width	450mm	650mm	700mm	900mm	1000mm
take up motor	1.5kw	1.5kw	1.5kw	2.2kw	2.2kw

Winder

winder width	500mm	700mm	800mm	1000mm	1200mm
effective width	450mm	650mm	700mm	900mm	1000mm
winder motor	30kg	30kg	50kg	50kg	100kg
optional equipment	auto-loader device, film surface treater, air compressor, rotary die head,automatic winder

pictures for reference:

---
